• Model NO.：KM-307
• Size：Outside Diameter 10-194mm, Thickness 1-20mm
• Delivery Time：20-35 Days Ex Mill
• Sample：Can Be Provided
• Testing Way：The Third Party Test Acceptable
• Material Grade：T1,T5,T11,T22,P11,P12,P91
• Surface：Oiled or Black Painted
• Loading Port：Chinese Main Port
• MOQ：5tons , Each Size
• Transport Package：in Bundles or According to Customers′ Request
• Specification：ISO
• Trademark：kingmetal
• Origin：China
• Production Capacity：20000ton,Month

DIN/ EN 10305-1 42CRMO4 STEEL PIPE FOR GAS CYLINDER

42CrMo4 is an alloy structural steel with high strength, high hardenability, good toughness, small deformation during quenching, and high creep strength and endurance strength at high temperatures. 42CrMo4 steel is a modified AISI 4140 steel, mainly used in the manufacturing of seamless hydraulic cylinder or gas cylinder, heavy machinery, cranes, excavators and forklifts, etc.



Standard:DIN/ EN 10305-1; DIN/ EN 10305-4

Specification: Cold-drawn seamless

Delivery condition: BK, BKW, BK+S, GBK, NBK



Outer diameter:89-368mm

Wall thickness:4-185mm

length:5.8-12m

42CRMO4 CHEMICAL COMPOSITION:

C

Si

Mn

P

S

Cr

Mo

0.38~0.45

≤0.40

0.60~0.90

≤0.035

≤0.035

0.90~1.20

0.15~0.30



42CRMO4 PHYSICAL PROPERTY:

Grade

Tensile strength Rm

Yield strength YS

Elongation A(%)

42CrMo4

800-1100

650-900

≥13



We provide high-pressure steel pipes and steel plates to customers from all almost industrial fields. 42CrMo4 is a commonly used alloy material specified in EN 10297-1 standard, and the main heat treatment is normalizing or annealing. Worldiron&steel offers 42CrMo4 seamless steel pipes in various sizes and specifications even the sizes that are hard to find. If you are looking for this material, please contact us or get a quote.
