• Model NO.：ASTM A234 WP5, WP9, WP11, WP22, WP91
• Dimensions：ASME,ANSI B16.9, ASME B16.28, Mss-Sp-43
• Transport Package：Bundle, Wooden Case
• Specification：2 NB to 18NB
• Trademark：C,N
• Origin：China
• Production Capacity：1000 Ton,Month

Basic Info.

Model NO. ASTM A234 WP5, WP9, WP11, WP22, WP91 Dimensions ASME/ANSI B16.9, ASME B16.28, Mss-Sp-43 Transport Package Bundle, Wooden Case Specification 2 NB to 18NB Trademark C/N Origin China Production Capacity 1000 Ton/Month

Product Description

Alloy Steel Pipe Bend
Carbon Steel Seamless Pipe Bend
Stainless Steel Long Radius Bend
Alloy Steel Buttweld Piggable Bend
Carbon Steel Pipe Bends
Stainless Steel Mitered Pipe Bend



ansi b16.9 buttweld hot induction bends
alloy steel j pipe bend
alloy steel customized pipe bend wholesaler
duplex steel pipe bends
astm a403 ss seamless pipe bends
90 degree welded pipe bend dealer
chrome moly u pipe bend exporters
alloy steel high pressure bending distributors
stainless steel buttweld pipe bends




Pipe Bends Specifications

Size	2″NB TO 18″ NB
Type	Seamless / ERW / Welded / Fabricated
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Bending angle	15°, 30°, 45°, 60°, 90°, 135°, 180°.
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Stainless Steel Long Radius Bend	ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Duplex & Super Duplex Steel Long Radius Bend	ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werkstoff No. 1.4462
Carbon Steel Long Radius Bend	ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Long Radius Bend	ASTM A420 WPL3, A420 WPL6



Grade Specifications	ASTM A234 & ASME SA234 WP5 Alloy Steel Pipe Bends
Size Range	Seamless Pipe Bends (1/2" - 24"), ERW / Welded / Fabricated Pipe Bends (2" - 36")
Outer Diameter	38.0 mm - 206.0 mm
Type	Seamless / Welded / Fabricated / Forged
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Size Range	Seamless Pipe Bends (1/2" - 24"), ERW / Welded / Fabricated Pipe Bends (2" - 36")
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Wall Thickness	1.5 mm / 2.0 mm / 3.0 mm - greater wall thickness at request
Bend Radii	75 / 100 / 150 / 250 / 300 / 500 / 800 / 1,000 / 1,200 / 1,500 mm
Bending angle	15°, 30°, 45°, 60°, 90°, 135°, 180° and also could manufacture according the angles given by the clients.
Weight	Weight (Kg)=[0.0433(D-T)TRθ]/100000+L(the weight of two ends straight bend)
Applicable Manufacturing	SME B16.9, ASME B16.28, ASME B16.25, MSSSP-75, DIN2605, JISB2311 JISB2312, JISB2313, BS, GB, ISO
Standards	1-ASME B 16.9 for large Bore 2-ASME B 16.11 for small Bore (socket welded) 3-ASME B 16.25 for butt weld ends 4-ASME B 16.28 for small radius elbow
End Bevel	According to the bevel of welding pipe fittings construction
ASTM A234 WP5 Alloy Steel Pipe Bend End Prep:	Beveled Ends Squared Ends Flanged Ends Cut Grooves Grooves Threaded Ends (Male & Female)
