S31803 U-Bend Stainless Steel Tube
Tianjin TEDA Ganghua Trade Co., Ltd.- Section Shape：Round
- Surface Treatment：Acid Pickling
- Usage：Pipeline Transport, Special Purpose, Machinery Industry, Chemical Industry, Mining, Heat Exchanger
- Technique：Cold Rolled
- Type：Seamless
- Finish：Acid Washing
Base Info
- Trademark：TJGH
- Specification：T: 0.8-50MM; OD: 5-1090 MM
- Transport Package：Standard Export Package: Wooden Box,Bundle
- Grade：S31803, S32205, S32750
- Length：Max 38 Meters
- Model NO.：S31803, S32205, S32750
- Origin：China
- HS Code：7304419000
- Production Capacity：10000ton,Month
Description
| Chemical Content of Typical Duplex Stainless Steel | |||||||||
| Grade | C | Mn | P | S | Si | Cr | Ni | Mo | Others |
| UNS S32101 | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.030 | ≤1.0 | 20.0-23.0 | 1.0-3.0 | ≤0.6 | N: 0.05-0.17, Cu: ≤1.0 |
| UNS S32304 | ≤0.03 | ≤2.5 | ≤0.04 | ≤0.040 | ≤1.0 | 21.5-24.5 | 3.0-5.5 | 0.05-0.6 | N: 0.05-0.20, Cu: 0.05-0.6 |
| UNS S31803 | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.020 | ≤1.0 | 21.0-23.0 | 4.5-6.5 | 2.5-3.5 | N: 0.08-0.20 |
| UNS S32205 | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.020 | ≤1.0 | 22.0-23.0 | 4.5-6.5 | 3.0-3.5 | N: 0.14-0.20 |
| UNS S32750 | ≤0.03 | ≤1.2 | ≤0.035 | ≤0.020 | ≤0.8 . | 24.0-26.0 | 6.0-8.0 | 3.0-5.0 | N: 0.14-0.20, Cu: ≤0.5 |
| Available Sizes | |||||||||
| Products | OD | WT | Length | ||||||
| Inch | MM | Inch | MM | Ft max. | M max. | ||||
| Tube | 1/2"-3" | 12.0-76.2 | 0.02"-0.5" | 0.5-12.0 | 105' | 32 | |||
| Pipe | NPS1/2"-6" | 21.34-168.3 | Sch10-Sch80 | 2.11-12.7 | 98' | 30 | |||
| Super Length Tube/Pipe is our advantages. | |||||||||
