• Model NO.：KM-307
• Lenght：3~12m or as Required
• MOQ：500kgs
• Certificate：ISO ,Ce,SGS,BV
• Surface：Annealing, Pickling, Polishing, Bright, Sand Blas
• Delivery Times：15 Days
• Thickness：Sch5s~Sch160,Xxs
• Brand：Km
• Transport Package：Standard Export Sea-Worthy Packing
• Specification：1,2"~64"
• Trademark：KINGMETAL
• Origin：Chinese Main Port
• Production Capacity：1000 Tons , Month

Incoloy 625 Seamless Pipes Specifications

Specifications:ASTM B517 / ASME SB 517Dimensions:ASTM, ASME and APISeamless 825 Pipes:4 to 219mm W. T.: 0.5 to 20mmWelded 825 Pipes:5.0 mm - 1219.2 mmEFW 825 Pipes:5.0 mm - 1219.2 mmSize:15″NB TO 150″NB INSpecialized in:Large Diameter SizeSchedule:SCH5, SCH10, SCH40, STD, SCH80, SCH160Type:Seamless / ERW / Welded / Fabricated / LSAW PipesForm:Round, Hydraulic EtcLength:Single Random, Double Random & Cut Length.End:Plain End, Beveled End, Treaded

INCONEL 625 SEAMLESS PIPES EQUIVALENT GRADE

STANDARD WERKSTOFF NR.UNSJISBSGOSTAFNORENORInconel 6252.4856N06625NCF 625NA 21ХН75МБТЮNC22DNB4MNiCr22Mo9NbЭИ602





INCONEL 625 WELDED PIPE CHEMICAL COMPOSITION

Grade CMnSiPSNiCrFeMoCoAlTiNb + TaInconel 6250.10 max0.50 max0.50 max0.015 max0.015 max58.0 min20.0 - 23.05.0 max8.0 - 10.01.0 max0.40 max0.40 max3.15 - 4.15



ALLOY 625 RECTANGULAR PIPE MECHANICAL PROPERTIES

Density Melting PointTensile StrengthYield Strength (0.2%Offset)ElongationInconel 6258.4 g/cm31350 °C (2460 °F)Psi - 135,000 , MPa - 930Psi - 75,000 , MPa - 51742.5 %



APPLICATIONS INDUSTRY

• Pharmaceutical Equipment
• Chemical Equipment
• Sea Water Equipment
• Heat Exchangers
• Condensers
• Pulp and Paper Industry

• Off-Shore Oil Drilling Companies
• Power Generation
• Petrochemicals
• Gas Processing
• Specialty Chemicals
• Pharmaceuticals
