• Transport Package：Wooden Box or Customer′s Request
• Specific Heat：460 - 460
• Thermal Conductivity：25 - 25
• Yield Strength：350 - 550
• Fatigue：275 - 275
• Elongation：8 - 25
• Tensile Strength：650 - 880
• Packing：by Sea, Air
• OEM：Yes
• Delivery Time：7-12 Days.
• Certificate：SGS ISO
• Application：Die Steel Bar
• Special Use：Mold Steel
• Model NO.：1.3348
• Specification：20-400mm
• Trademark：Taixie
• Origin：Wuxi, China
• HS Code：7228300000
• Production Capacity：1000t,Mon

Basic Info.

Model NO. 1.3348 Special Use Mold Steel Application Die Steel Bar Certificate SGS ISO Delivery Time 7-12 Days. OEM Yes Packing by Sea, Air Tensile Strength 650 - 880 Elongation 8 - 25 Fatigue 275 - 275 Yield Strength 350 - 550 Thermal Conductivity 25 - 25 Specific Heat 460 - 460 Transport Package Wooden Box or Customer′s Request Specification 20-400mm Trademark Taixie Origin Wuxi, China HS Code 7228300000 Production Capacity 1000t/Mon

Product Description

1. 1.3348 High Speed Tool Steel Bar Tool Steel Rod
2. Hot rolled or Forged, condition annealing, black surface
3. Hardness: ≤ 255HBS;
4. Hot rolled technology: EAF+LF+VD
5. Ultrasonic test standard: SPE1921-GR3, CLASS D/D or E/E

Applications:
1. Diecasting mould(mold, fixed block, upper die, jet nozzle, nitride thimble ).
2. Extrusion die(mold, supporting member,  choke blocks).
3. Hot press die. (aluminum, magnesium, copper alloy)
4. Parts, such as cold cutting, overlap, hot shears, wearable parts.
5. Important parts for aviation industry.

Packing details	In seaworthy packing, as your requirement.
Delivery details	within 7-12 days

 Chemical Composition:

Grade	C	Si	Mn	P	S	Cr	Mo	V	W
1.3348	0.95- 1.05	0.70 max	0.40 max	0.030max	0.030max	3.50- 4.50	8.20-9.20	1.70-2.20	1.50- 2.10

Company Profile
WuXi TaiXie Metal Material Co., Ltd.Is Located in the Large South Stainless Steel Markets, and established July 2009.We are also One of the Powerful Company In the Stainless Steel and Mould steel Area.We have our own factory,we main export steel,copper,aluminum,iron,ect.

FAQS:
Q:How to get a formal effective quotation?
A:According to your required specification, such as material(Article) ,main dimension, and the quantity you need, we will provide a formal effective quotation within a working days.
Q:How to deal with the parts received when they are found to be in poor quality?
A:Please rest assured that all our products are QC inspected completely and accepted with inspection report before delivery.Generally there will no non-conformance.In case of non- conformance, and the errors identified was caused by us, we will arrange to repair or make right parts for you.
Q:What is the MOQ?
A:Usually we don't set MOQ, but the more, the cheaper.Besides, we are happy to make prototype or sample for clients to ensure quality standard.
Q:Whether some samples can be provided ?
A:Yes, just need some sample cost, we will return it back when proceed into mass production.
Q:If we can not find what we want on your website, what should we do?
A:You can email us the descriptions and pictures of the products you need, we will check whether we have them.We develop new items every month, and some of them have not been uploaded to website in time.Or you can send us sample by express, we will develop this item for bulk purchasing.
