• Origin：China
• Specification：1220*2440, 1500*3000, 1500*6000, 2000*6000mm
• Transport Package：Wooden Pallet Wooden Box
• Surface Treatment：Pickling
• HS Code：7219340000
• Production Capacity：50000kgs

Basic Info.

Surface Treatment Pickling Transport Package Wooden Pallet Wooden Box Specification 1220*2440, 1500*3000, 1500*6000, 2000*6000mm Origin China HS Code 7219340000 Production Capacity 50000kgs

Product Description

High Quality S31803 Duplex Stainless Steel Plate Supplier Thickness 3.0 - 20.0mm SS Sheets in Stock

2205 is a duplex (austenitic-ferritic) stainless steel containing about 40 - 50% ferrite in the annealed condition. 2205 has been a practical solution to chloride stress corrosion cracking problems experienced with 304/304L or 316/316L stainless. The high chromium, molybdenum and nitrogen contents provide corrosion resistance superior to 316/316L and 317L stainless in most environments. 2205 is not suggested for operating temperatures above 600°F.

The design strength of 2205 is significantly higher than 316/316L, often permitting lighter wall construction. 2205 has good notch impact toughness down to temperatures below - 40°F. 2205 is welded with E2209 or ER2209 fillers.



Features

• High resistance to chloride stress corrosion cracking
• Chloride pitting and crevice corrosion resistance superior to 317L stainless
• Good general corrosion resistance
• High strength
• Good sulfide stress corrosion resistance
• Useful up to 600°F

Applications

• Chemical process vessels, piping, and heat exchangers
• FGD scrubber systems
• Pulp mill digesters, bleach washers, chip presteaming vessels
• Food process equipment
• Oil field piping, heat exchangers

Specifications:



UNS S31803

ASME SA-182 (F51), SA-240, SA-798, SA-790, SA-815
ASTM A182 (F51),A240, A276, A479, A789, A790, A815, A928, A988
SAE J405



UNS S32205

ASME SA-182 (F60), SA-240, SA-798, SA-790, SA-815
ASTM A182 (F60), A240, A276, A479, A480, A798, A790, A815, A928, A988
SAE J405
