Is a Carbon Wear-Resistant Steel Plate
QINGHE SANJU TRADING CO., LTD.- Type:Plate
- Standard:AISI, ASTM, DIN, JIS, GB, BS
- Composition:Stainless Steel Scrap
- Technique:Alloy
- Shape:Flat
- Surface Treatment:Mill Finish
Base Info
- Special Use:High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Cold Heading Steel, Free Cutting Steel, Mold Steel
- Application:Construction Decoration
- Package:Standard Export Package
- Transport Package:as Custome′ S Required
- Specification:as Custome′ s Required
- Trademark:SANJU
- Origin:Hebei
- HS Code:7208511000
- Production Capacity:400000,Year
Description
HH-650 Bimtetal Chromium Carbide Overlay Weld Wear Resistant steel Plate
C:4.3-4.8%, Cr:20-26%,
Heat resistance maximum up to 350 ºC. Hardness: 57-62 HRC
C:4.3-5.0%, Cr:23-28%,
Heat resistance maximum up to 500 ºC. Hardness: 57-62 HRC
C:4.3-5.0%, Cr:27-35%,
Heat resistance maximum up to 500 ºC. Hardness: 58-63 HRC
Other Feature and Property
1. Chemical composition: Bimtetal Chromium Carbide Overlay Weld Wear Resistant steel Plates are manufactured by welding one or multiple abrasion resistant layers on Mild steel (Q235, Q345) or stainless steel (SS 304, SS 309, SS 310) base plate.
2. The overlay alloy has a high amount of chromium carbide hard particles.
3. Microstructure: The carbide (Cr7C3) volum fraction on the microstructure is above 50%.
4. Rockwell Hardness: Chromium carbide hard particles are distributed evenly throughout the layer, creating a strong microstructure,
5. The hardness is between HRC 57-62 and depend on the overlay's thickness: Overlay thickness over 10 mm. Hardness over 62 HRC.
6. Wear resistance: Our test shows that the Abrasion resistant performance of Bimtetal Chromium Carbide Overlay Weld Wear Resistant steel Plate is 20 times higher than Mild steel and 8 times than heat treated steel.
7. Flatness tolerance: Flatness tolerance is ±3mm/m.
8. Thickness tolerance: Uniform overlay thickness, with tolerance within 0-0.3mm.
