• Model NO.：20MnCr5 Hot Rolled Round
• Special Use：High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Cold Heading Steel, Free Cutting Steel, Mold Steel
• Application：Tool Steel Bar
• Transport Package：Nude Packing
• Specification：Diameter: 10-300mm
• Trademark：Ningbo Ningshing
• Origin：China

Basic Info.

Model NO. 20MnCr5 Hot Rolled Round Special Use High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Cold Heading Steel, Free Cutting Steel, Mold Steel Application Tool Steel Bar Transport Package Nude Packing Specification Diameter: 10-300mm Trademark Ningbo Ningshing Origin China

Product Description

DIN20MnCr5| 20MnCrS5AlloySteelBar

Dimensions
Hot Rolled Round: dia.10-300 mm


Delivery Condition
EAF+LF+VD, Hot Rolled or Forged, Black or Machined, Annealed, UT 100% Passed

Equivalence

AISI / SAE	DIN / W.Nr	JIS	GB
5120	20MnCr5 20MnCrS5 1.7147	----	20CrMn

Chemical Composition(%)

Steel Grade	C	Si	Mn	P	S	Cr
20MnCr5	0.17-0.22	≤ 0.40	1.10-1.40	≤ 0.035	≤ 0.035	1.00-1.30
20MnCrS5	0.17-0.22	≤ 0.40	1.10-1.40	≤ 0.035	0.020-0.040	1.00-1.30

Characteristics
DIN 20MnCr5 / 20MnCrS5 grade is a low-alloy steel containing chromium as strengthening agent. The steel has good strength and toughness in low temperature, hardenability and machinability, less deformation after heat treatment, but poor weldability

Applications
This low-alloy steel can be case hardened, or quenched and tempered, for carburized parts as well as quenched and tempered parts with large section under heavy bent load and speed, such as gear, connecting rod, shaft, worm, sleeve, friction wheel, gear pump without heavy impact, water pump rotor, clutch, bolt for high pressure vessel, etc.
