• Trademark：SANJU
• Origin：Hebei
• HS Code：730890
• Production Capacity：50000t,Years

Basic Info.

Trademark SANJU Origin Hebei HS Code 730890 Production Capacity 50000t/Years

Product Description

SPECIFICATIONS:


Place Of Origin:	HEBEI, China
Application:	Construction, Insulating, Chemical Plant, Water Treatment, etc.
Surface Treatment:	Smooth, Paint Or Customer Request
Technique:	Pultrusion Process
Measurement:	Customizable
Resin Type:	Vinyl Resin,phthalic Resin ,ISO,Epoxy Resin
Color:	Black , White , Red , Green , Yellow , Blue , Grey Or Customized Color
Feature:	Light Weight, High Strength , Impact, Fatigue Resistant, Non-conductive, Non-magnetic, Easy Assembly, Dimensional Stability, Maintenance Free, Corrosion Resistant, Fire Retardant

Example Diagram Based On ASTM Testing Standard, Our Products Could Meet Many Other Standards Such As: EN13706; GB; CTI etc.

Property	Test Method	Units	Mean-Value LW/CW
Tensile Strength	ASTM D638/GB1447	Mpa	240 / 50
Tensile Modulus	ASTM D638/GB1447	Gpa	23 / 7
Flexural Strength	ASTM D790/GB1449	Mpa	300 / 100
Flexural Modulus	ASTM D790/GB1449	Gpa	18 / 7
Compressive Strength	ASTM D695/GB1448	Mpa	240 / 70
Compressive Modulus	ASTM D695/GB1448	Gpa	23 / 7.5
Interlaminar Shear(lw)	ASTM D2344	Mpa	25
Charpy impact Strength	ISO 179/GB1451	KJ/m²	240
Barcol Hardness	ASTM D2583	HBa	50
Density	ASTM D792	--	1.9
Flammability Classification	UL 94/GB8924	--	VO(40)
Tunnel Test	ASTM E84	--	25 Max
Water Absorption(MSX.)	ASTM D570/GB1462	%	0.57 Max.by weight
