ASTM A53 BS1387 G. I. Pipes/Galvanized Pipes

Guangzhou Kingmetal Steel Industry Co., Ltd.
  • Usage：Pipeline Transport, Special Purpose, Chemical Industry, Construction & Decoration
  • Surface Treatment：Galvanized
  • Technique：Hot Rolled
  • Material：Carbon Steel
  • Type：Welded
  • Section Shape：Round

Base Info

  • Transport Package：in Bundle
  • Min Order Qty：5 Tons
  • Pipe Ends：Plain,Bevel or Threaded Wtih Caps
  • Materials：Gr.a,Gr.B,Q235B,etc
  • Surface：Hot Dipped Galvanizing,Electro Galvanizing
  • Wall Thickness：0.8~ 8mm
  • Outer Diameter：20 ~ 219mm
  • Model NO.：KM-065
  • Specification：20~219mm
  • Trademark：Kingmetal
  • Origin：Made in China
  • HS Code：73069000
  • Production Capacity：5000 Tons Per Month

Description

Dimensions, nominal weight, etc., of Black and Galvanized Steel TubesConforming to BS: 1387 / Is 1239NB &Approx OutersWallApprox Weight of tubesSocketsSeriesDiameterThicknessPlain EndScrewed & Socketed

 mm (inches)Min. mmMax. mmmmGuageKg / MtrMtrs / MTNo.of PipesKg / MtrMtr / MTNo of PipesO.D.Length15 (1/2") L2121.42140.94710561750.95610461742737M2121.72.6121.218261371.22820136

 H2121.73.2101.446941151.45690114

 20 (3/4") L26.426.92.3131.387251201.3971911932.539M26.527.22.6121.566411071.57637106

 H26.527.23.2101.87533891.8853288

 25 (1") L33.233.82.6121.985058425008339.546M33.434.23.2102.41415692.4341268

 H33.434.2482.94340572.9633856

 32(11/4") L41.942.52.6122.54394662.57389654951M42.142.93.2103.1323543.1331953

 H42.142.9483.8263443.8326243

 40(11/2") L47.848.42.9113.57310523.27306515651M4848.83.2103.56280473.6127746

 H4848.8484.38228384.4222637

 50 ( 2") L59.660.22.9114.08245414.15241406860M59.860.83.695.03199335.119632

 H59.860.84.576.19162276.2616026

 65 (21/4") L75.2763.2105.71175295.83172288469M75.476.63.696.43156266.5515325

 H75.476.64.577.93126218.0512420

 80 (3") L87.988.73.2106.72149256.89145249875M88.189.5488.37119208.5411719

 H88.189.55610.3971710.59516

 100(4") L113.9113.93.699.7510317101001612487M113.3114.94.5712.2821412.58013

 H113.3114.95.4514.5691214.86811

 Bitmap
Tolerances (BS 1387)
Thickness Full-HardLightMediumHeavy-8%-10%-10%WeightLight, Medium & Heavy Tubes 165For single Tube +/- 10%LengthLight, Medium & Heavy TubesTubes Random Length of 4 to 7 metres unless specified otherwiseBitmap
Tolerances (IS 1239)
Thickness Full-HardLight Tubes-8%, + not limitedMedium & Heavy Tubes-10%, + not limitedWeightSingle Tube Light Class+10%, -8%Single Tube (Medium & Heavy Class)+/- 10%Per 10 MT load (Light Class)+7.5%, -5%Per 10 MT load (Medium & Heavy Class)+/-7.5%LengthLight, Medium & Heavy TubesRandom length of 4 to 7 mtrsunless specified otherwise
