201/304/304L/316L Stainless Steel Sheet by Cold/Hot Rolled
Shanghai Huagang Steel Co., Ltd.- Certification：ISO, RoHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
- Grade：300 Series
- Standard：ASTM, AISI, GB, JIS, DIN, EN
- Type：Stainless Steel Sheets
- Shape：Square
- Technique：Cold Rolled
Base Info
- 400 Series Steel：409L, 410, 410s, 420, 420j1, 420j2, 430, 444, 441
- 200 Series Steel：201, 202, J1, J2, J3, J4
- Material：Stainless Steel
- Special Use：Cutting Tools, Measuring Tools, Cutters in Common
- Edges：Mill Edge, Slit Edge
- Surface Technics：Flat,Corrugated,Perforated,Embossed,Water Ripple
- Duplex Steel：904L, 2205, 2507, 2101, 2520, 2304
- 300 Series Steel：301, 304, 304L, 314, 316, 316L, 316ti
- MOQ：1 Ton
- Price Term：CIF CFR Fob Ex-Work
- Stock：Stock
- Application：Mold & Dies, Ship Plate, Boiler Plate, Container P
- Model No.：201, 202, 301, 302, 303, 304, 304L, 304h, 309
- Surface Treatment：Polished
- Model NO.：S30100 301 SUS301 X5CRNI17-7 1.4319 S30400 304
- Surface：No.1,2b,Ba,Hairline,Polished,Mirror,8K,Color
- Color：Golden,Rose Gold,Silver,Black,Red,Green,Blue,etc
- Transport Package：Standard Seaworthy Export Packing
- Specification：4X8FT,5X10FT,Customize
- Trademark：HGS
- Origin：Shanghai
- HS Code：7304411000
- Production Capacity：50000pieces,Year
Description
Stainless Steel SheetGrade 304, 304/304L, 316, 316/316L, 2205, 4003/3CR12 & 4003Ti/3CRTi. Thickness (mm) 0.45 to <3.0. Width (mm) 914, 1219, 1500, 2000 & customer specific width. Length (mm) 1829, 2438 & customer specific length. Finish 2B, No.4, BA & customer specific polish. Standard coating Paper interleaf & PE. Optional coating Laser & Deep drawing PVC. Plasma profiles To customer drawings.
Stainless 304 Specifications
ASTM A240 B210
AMS 5511 5513 5647
ASME SA-240Mechanical Information Density Ultimate Tensile Strength Yield Tensile Strength Imperial 0.289 lb/in3 73,200 psi 31,200 psi Metric 8.0 g/cc 310 MPa 276 MPa Modulus of Elasticity Shear Modulus Melting Point Imperial 28,000 ksi 11,200 ksi 2,550-2,651 F Metric 193 GPa 77 GPa 1,400-1,455 C Hardness Rockwell/Brinell Elongation at break percentage Poissons Ratio B70/123 70 0.29 Element Percentage C 0.08 max Cr 20 Fe 66.34 - 74 Ni 8 - 10.5 Mn 2 max P 0.045 max S 0.03 max Si 1 max
Our Steel has from years of experience determined the popular range of grades, widths and thicknesses of stock. The standard range is as follows:
Shanghai Huagang Steel Co., Ltd. is one of the leading manufactories with ISO 9001 certificate who is specializing in manufacturing & exporting various kinds of steel pipes, steel plate, steel coil, round bar, flat bar, angle bar, H beam and other steel products in China. We owned the complete production technique and related equipment for coking, sintering, iron, steel, steel rolling etc, also including the related energy source power system. Meanwhile, we have reached the production technique` s completeness and systematicness at the modern steel industry. The company's annual sales amount is more than 100 million yuan.
Through the global sales network, the products sell well in domestic and foreign markets, Huagang Steel has exported steel products to over 100 countries in the world. Our products are marketed widely all over the country and exported to North American, Europe, Middle East, South American, Southeast Asia, Africa, Australia etc and get highly appreciated for our quality and service.
We now have 5 branch offices in China now, the head factory is located in ChenQiao Road, Fengxian District, Shanghai.We have been engaged in stainless steel business since 2009,with 12 years growth,Huagang Steel has become a competitive steel conglomerate in China.
Our company aims to provide customers with high-quality and low-price steel products and strives to create value for customers. We have advanced processing equipment and powerful logistics distribution system, which can meet customers' various needs at any time.
We adhere to the principle of "customer first" to provide our customers with high-quality services. Our company has won the trust and praise from customers with the business advantages of complete specifications, cheap price and fast transmission, and the service concept of keeping promise and focusing on quality.
FAQ
Q1.Are you a manufacturer or trader?
We are a manufacturer ,and we can have our own factory produced many steel products.
Q2.Whether your company supports Trade Assurance order?
Yes , we can (100% product quality protection;100% on-time shipment protection; 100% payment protection)
Q3.Can we get the some samples?Any charges?
Yes,you can get available samples in our stock.If the samples from new production, we will charge some reasonable cost, but this amount will be deducted from your first order.
Q4.How do we build up business relations with your company ?
Send us your requirement which includes size , coating info ,parameters,quantity ,destination .
Q5.What is the MOQ?
We can accept small orders.Please feel free to contact us, we can meet your requirements.
Q6.What's your advantage?
With high-quality products and efficient customer service, we adhere to the principle of customer first.
Stainless 304 Specifications
ASTM A240 B210
AMS 5511 5513 5647
ASME SA-240Mechanical Information
The information provided is for standard stock product and does not encapsulate all available combinations. Please contact your nearest Steels Service Centre if non standard product is required and we will enquire about its availability through our global supply network of mills and stockists.
For more technical information there are excellent reference manuals and data sheets contained within the technical library of this website.
Stainless steel sheet, 0.45mm to less than 4.0mm - ASTM A240MOur Steel has from years of experience determined the popular range of grades, widths and thicknesses of stock. The standard range is as follows:
| Grade | Finish | Thickness (mm) | Width (mm) | Length (mm) |
| 304 | 2B & No. 4 PE | 0.55 | 914 & 1219 | 1828 & 2438 |
| 304 | 2B & No. 4 PE | 0.7 | 914 & 1219 | 1828 & 2438 |
| 304 | 2B, 2B PE, No. 4 PE & BA PE | 0.9 | 914 & 1219 | 1828 & 2438 |
| 304 | 2B, 2B PE, No. 4 PE & BA PE | 1.2 | 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 304 | 2B, 2B PE & No. 4 PE | 1.5 | 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 304 | 2B, 2B PE & No. 4 PE | 1.6 | 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 304 | 2B, 2B PE & No. 4 PE | 2 | 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 304 | 2B, 2B PE & No. 4 PE | 2.5 | 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 304 | 2B, 2B PE & No. 4 PE | 3 | 914, 1219 & 1500 | 1828, 2438, 3000, 3048 & 3658 |
| 304L | 2B & 2B PE | 4 | 1500 & 2000 | 3000 & 6000 |
| 316 | 2B | 0.55 | 1219 | 2438 |
| 316 | 2B | 0.7 | 1219 | 2438 |
| 316 | 2B | 0.9 | 1219 | 2438 |
| 316 | 2B & No. 4 PE | 1.2 | 1219 | 2438 |
| 316 | 2B & No. 4 PE | 1.5 | 1219 & 1500 | 2438, 3000 & 3658 |
| 316 | 2B & No. 4 PE | 1.6 | 1219 & 1500 | 2438, 3000 & 3658 |
| 316 | 2B & No. 4 PE | 2 | 1219 & 1500 | 2438, 3000 & 3658 |
| 316 | 2B & No. 4 PE | 2.5 | 1219 & 1500 | 2438, 3000 & 3658 |
| 316 | 2B & No. 4 PE | 3 | 1219 & 1500 | 2438, 3000 & 3658 |
| 316L | 2B & 2B PE | 4 | 1500 & 2000 | 3000 & 6000 |
| 430 | BA PE & No. 4 PE | 0.7 | 914 & 1219 | 1828 & 2438 |
| 430 | BA PE & No. 4 PE | 0.9 | 914 & 1219 | 1828 & 2438 |
| 3CR12 | 2B | 1.2 | 1250 | 2500 |
| 3CR12 | 2B | 1.6 | 1250 | 2500 |
| 3CR12 | 2B | 2 | 1250 | 2500 |
| 3CR12Ti | No. 1 | 3 | 1250 & 1500 | 2500, 3000 & 6000 |
| 3CR12 | No. 1 | 4 | 1250 & 1500 | 2500, 3000 & 6000 |
Other grades and widths
Product outside the standard range can be indented from overseas mills or stocked by special arrangement.
