Tp347 Seamless Pipes/Welded Pipes (AISI 347, UNS S34700, 1.4550, TP 347)
JIANGSU LIANGYI CO., LIMITED- Usage：Pipeline Transport
- Surface Treatment：Polish
- Material：Stainless Steel
- Technique：Hot Rolled
- Type：Seamless
- Section Shape：Round
Base Info
- Trademark：LY
- Specification：CE
- Transport Package：Bundle and Wooden Box Packing
- Material Grade of Pipes：AISI 347
- Model NO.：jj915
- Origin：Jiangyin
- HS Code：722840000
- Production Capacity：5000 Tons,Year
Description
Carbon
0.08 max
Chromium
17 - 19
Iron
Balance
Manganese
2 max
Nickel
9 - 13
Niobium
Min:5 x C
Phosphorus
0.045 max
Silicon
1 max
Sulphur
0.03 max
The mechanical property of 347 bars is as follows
0.2% Yield Strength MIN
Ultimate Tensile Strength MIN
% Elongation in 2" (50.8mm) MIN
% Reduction of Area MIN
Brinell Hardness
Izod Impact Strength
ksi
Mpa
ksi
Mpa
Ft-lb
J
37
255
90
621
50
65
150
110
149
