Pre-Painted Painting Color Coated Steel Coil (SGCC)
CHANGZHOU DINGANG METAL MATERIAL CO., LTD.- Standard：ASTM, JIS, GB
- Certification：ISO
- Surface Treatment：Coated
- Technique：Cold Rolled
- Application：Marble Pattern
- Edge：Mill
Base Info
- Model NO.：SGCC
- Stock：Stock
- Thickness：0.18-1.5mm
- Width：30-1250mm, Mainly in 914, 1000, 1219, 1250mm
- Surface Finished Color：According to Ral Standard
- Coating Thickness：Single Side :50-225 G,Sqm
- Inside Diameters：508 Mm
- Outside Diameter：According to The Weight of Coil
- Weight Coil：3-8 Tons
- Transport Package：Seaworthy Packing, Export Standard
- Specification：ASTM, GB, JIS
- Trademark：Dingang, OEM
- Origin：Jiangsu, China(Mainland)
- HS Code：72107010
- Production Capacity：30, 000 Ton,Tons Per Year
Description
|
Coat Type |
Dope Type |
Coat Thickness (μm) |
Rigidity Of Pencil |
Shine 60°(%) | Bend |
Return Impact(J) |
Salt Spray Tolerance(H) |
||||
| High | Middle | Low |
Thickness≤0.75mm (Steel window≤0.8 mm) 180°T |
Thickness>0.75 mm(Steel window>0.80mm) |
|||||||
| A | B | ||||||||||
|
Second Coat |
PE | ≥20 | ≥F | >70 | 40-70 | <40 | ≤3T | ≤5T | 90° | ≥9 | ≥500 |
| SMP | ≥20 | ≥F | >70 | 40-70 | <40 | ≤3T | ≤5T | 90° | ≥9 | ||
| PVDF | ≥20 | ≥F | -- | 40-70 | <40 | ≤2T | ≤5T | 90° | ≥9 | ≥1000 | |
| Plastisol | ≥100 | -- | -- | 40-70 | <40 | ≤1T | ≤5T | 90° | ≥9 | ||
| First | PE | ≥10 | ≥HB | >70 | 40-70 | <40 | ≤3T | ≤5T | 90° | ≥9 | ≥250 |
