• Specification：1,2′′ - 48′′
• Transport Package：Export Standard Sea-Worthy Packing
• Length：5.8m, 6m, 3000-12000mm
• Product Name：Pre-Insulated Pipe,Under Ground Pipe
• Section Shape：Round
• Usage：Pipeline Transport
• Trademark：kingmetal
• Origin：China Mainland

Basic Info.

Usage Pipeline Transport Section Shape Round Product Name Pre-Insulated Pipe/Under Ground Pipe Length 5.8m, 6m, 3000-12000mm Transport Package Export Standard Sea-Worthy Packing Specification 1/2′′ - 48′′ Trademark kingmetal Origin China Mainland

Product Description

Seamless Carbon Steel Pre-insulated Pipe

The preinsulated pipe system is made up of steel carrier pipe, 100% CFC free polyurethane insulation foam and seamless solid wall HDPE jacket. Steel carrier pipe may vary according to project specification; from ERW (Electric resistance welded), SAW (Submerged arc welded) or Seamless pipes with wall thickness from Std, Sch 40, XS.

The insulation is made of 100% CFC free polyurethane foam. The required amount of foaming mixture, usually 25% over packed, is injected into the cavity between the steel core and the casing pipe via the injection hole in the metal end caps at the top of the pipe assembly. Air vent plugs are fitted on the metal end caps to dispense the air entrapped.

• Thermal conductivity: In the range of 0.0230 to 0.0280 W/mK
• Core density: 48 to 90 kg/m3 or as per customer requirement
• Thickness: recommended 50mm or as per customer requirement
• Compressive strength: 300 KPa (minimum)
• Blowing agent: Water based, 141b, solstice (EN253 certification)

• The outer casing or protective jacket shall be HDPE pipe, black, UV - resistant, having a minimum density of 950 kg/m3
• Outer casing diameter/wall thickness: As per EN253
