• Specification：1220*2440, 1500*3000, 1500*6000, 2000*6000mm
• Transport Package：Wooden Pallet
• Model NO.：DC01
• Trademark：TISCO BAO STEEL TAI STEEL MA STEEL
• Origin：China

Basic Info.

Model NO. DC01 Transport Package Wooden Pallet Specification 1220*2440, 1500*3000, 1500*6000, 2000*6000mm Trademark TISCO BAO STEEL TAI STEEL MA STEEL Origin China

Product Description



Grade :	DC01
Number:	1.0330
Classification:	Non-alloy quality steel
Standard:	EN 10130: 2006 Cold rolled low carbon steel flat products for cold forming. Technical delivery conditions     EN 10139: 1997 Cold rolled uncoated mild steel narrow strip for cold forming. Technical delivery conditions     EN 10152: 2009 Electrolytically zinc coated cold rolled steel flat products for cold forming. Technical delivery conditions     EN 10271: 1999 Electrolytically zinc-nickel (ZN) coated steel flat products. Technical delivery conditions
Equivalent grades:

Chemical composition %   of   steel   DC01 (1.0330):   EN 10130-2006

Unless otherwise agreed at the time of enquery and order, this grade may be supplied as alloy steel (for example with boron or titanium)

C	Mn	P	S
max   0.12	max   0.6	max   0.045	max   0.045

New opportunities for buyers!
Post free buying requirement   of   steel   DC01 (1.0330)


Mechanical properties of   steel   DC01 (1.0330)

Rm - Tensile strength (MPa)	270-410

ReH - Minimum yield strength (MPa)	280

A - Min. elongation Lo = 80 mm (%)	28

A - Min. elongation Lo = 5,65 √ So (%) (+A)	32

Vickers hardness  ( HV):   (+A)

105

Equivalent grades of   steel   DC01 (1.0330)
Warning! Only for reference

EU EN

USA -

Germany DIN,WNr

Japan JIS

France AFNOR

England BS

European old EN

Italy UNI

Spain UNE

China GB

Sweden SS

Czechia CSN

Austria ONORM

Russia GOST

Inter ISO

India IS

DC01

SAE1008 SAE1010

FeP01 St12

SPCC

C F12 FeP01

CR4 FeP01

FeP01

FeP01

AP00

08 08F

1142

11321

St02F

08kp 08ps

Cr01 CR22

O
