Corten Steel Grade A Plate

Guangzhou Kingmetal Steel Industry Co., Ltd.
  • Application：Mold & Dies, Ship Plate, Boiler Plate, Container Plate, Flange Plate
  • Technique：Hot Rolled
  • Surface Treatment：Milling
  • Certification：RoHS, IBR
  • Type：Steel Plate
  • Standard：ASTM, AISI, GB, JIS, DIN, BS

Base Info

  • Specification：thickness:0.3-100mm,width:1000~3500mm,length:1~12m
  • Transport Package：According to Standard Seaworthy Export Package
  • Stock：Not Stock
  • Special Use：Cutting Tools, Measuring Tools, Cutters in Common Steel, High-strength Steel Plate, Wear Resistant Steel, Silicon Steel
  • Model NO.：KM-20201210
  • Trademark：kingmetal
  • Origin：China
  • HS Code：7225991000
  • Production Capacity：5000tons Per Month

Description

Item

Corten Steel plates

Standard

ASTM A588, A242, EN 10027-1, CR 10260 & IRSM

Material

Corten A , Corten B , S235J0W , S235J2W , S355J0WP , S355J0W , S355J2W , S355K2W , A588 Grade A , A588 Grade B , A588 Grade C , A242 Type 1 , A 588 Gr. K , A 242 Type-2 , IRSM-41

Thickness

0.3-100mm

Width

1000-3500 mm

Length

1000 - 12000 mm

  Corten - AASTM 588 Grade AASTM 242 TYPE -1IRSM 41 -97Carbon, Max0.120.190.150.10Manganese0.20-500.80-1.251.000.25-0.45Phosphorus0.07-0.150.040.150.07-0.11Sulphur, max0.0300.050.050.030Silicon0.25-0.750.30-0.650.25-0.400.28-0.72Nickel, max0.650.40-0.20-0.49Chromium0.50-1.250.40-065-0.30-0.50Molybdenum, max----Copper0.25-0.550.25-0.400.20 min0.30-0.39Vanadium-0.02-0.10-0.050Aluminimum-…-0.030 APPLICATIONBRITISH STANDARDJAPANESEJISGERMAN
DINAMERICAN
ASTMAIR PRE HEATERSBS-6323-5
BS-6323-6JIS G 3445DIN 17177
EN 10217-1 AND 2
EN 10305-2 AND 3ASTM  A423
GR.1
ASTM A214  Tensile StrengthMin. Yield PointElongationCORTEN A[470 - 630 MPa][355 MPa]20 % minASTM 588 GR. A[485 MPa][345 MPa]21% minASTM 242 TYPE -1[480 MPa][345 MPa]16% minIRSM 41- 97[480 MPa][340 MPa]21% min
