• Origin：Shanxi Tisco
• Trademark：TISCO
• Specification：CE, BV, SGS, etc.
• Transport Package：Nude Packing, According to The Customer′s Request
• Thick Sheet：6-40mm
• Thin Sheet：3-5mm
• Model NO.：Mn13 X120Mn12
• HS Code：7225400000
• Production Capacity：500 Tons Each Month

Basic Info.

Model NO. Mn13 X120Mn12 Thin Sheet 3-5mm Thick Sheet 6-40mm Transport Package Nude Packing, According to The Customer′s Request Specification CE, BV, SGS, etc. Trademark TISCO Origin Shanxi Tisco HS Code 7225400000 Production Capacity 500 Tons Each Month

Product Description

Mn13 X120Mn12

Specifications
1. ASTM A128 standards, EN X120Mn12
2. DIN 1.3401, JIS SCMnH11
3. China National Standard GB Mn13
4. 11-14%Mn (Hadfield steel)

High Manganese Steel
X120MN12 1.3401 A128
High manganese steel 11-14%Mn (Hadfield steel)
We are exclusive export agents and distributors specializing in high manganese steel plates. Dealing directly with the steel mill, we are able to offer very competitive pricing.
Serving the shot blast industry, mining, railroad, foundries, quarries and steel mills. Wherever severe impact, abrasion and wear resistant steel is needed.

We can source for you:
Plates 3mm to 5mm thick, 900mm to 1100mm wide and up to 2200mm long
Plates 6mm to 40mm thick, 1500mm to 1800mm wide and up to 10000mm long

The characteristics of X120MN12:
High abrasive resistance, and impact toughness
Work hardening steel - the more impact and abrasion it gets the harder the surface becomes.
Steel stays ductile underneath - as the surface wears - only outer layer gets hard.
With continued impact the manganese steel can harden to HB500 above.
When rolled - never brittle.
Work hardened surface is almost friction-less.
Non-Magnetic
Quenched, annealed and austenitic
Can be cut by plasma / laser / water jet / oxy-acetylene
Made to ASTM A128 standards, EN X120Mn12, DIN 1.3401, JIS SCMnH11, and China National Standard GB Mn13

Chemical composition:
Mn 11.0/14.0
C 0.90/1.20
Si 0.30/0.80
P 0.035max
S 0.030 max

Mechanical Properties:
Tensile Strength: Min116000psi
Yield Strength: Min58000psi
%Elongation in 2": 35% t/50 %

Welcome To inquire about pricing, delivery or any other questions!

Brand	C	Si	Mn	P	S
X120Mn12	0.90-1.20	0.30-0.80	11.00-14.00	≤0.035	≤0.030





Mechanical Properties

Tensile Strength	Elongation	20°C Impact Resistance	Initial Hardness(HB)		180°old Bending Test
≥900MPa	≥40%	ak≥50(J)	190-250		Qualified
