• Model NO.：1.2564,DIN X30WCrV41
• Special Use：Cutting Tools, Cutters in Common Steel, High-strength Steel Plate
• Stock：Stock
• Transport Package：Nude Packing
• Trademark：boz
• Origin：China
• Production Capacity：5000tons,Month

AISI

Brand Name

DIN

EN

JIS

Ravne No.

BS

/

UTOP1

X30WCrV41

/

/

856

/

Chemical Composition (in weight %)

CSiMnCrMoNiVWOthers0.300.950.401.05--0.183.75-

Description
Tungsten-chromium hot work steel suitable for water cooling.

Applications
Water cooled dummy blocks for the extrusion of copper and copper alloys, hand casting chills for copper alloys.

Physical properties (avarage values) at ambient temperature
Modulus of elasticity [10³ x N/mm²]: 210
Density [g/cm³]: 7.80

Soft Annealing
Heat to 820-840^oC, cool slowly in furnace. Holding time 4-6 hours. This will produce a maximum Brinell hardness of 230.

Stress Relieving
Stress relieving to remove machining stresses should be carried out by heating to 650^oC, holding for one hour at heat, followed by slow cooling. Time is 1-2 hours. This operation is performed to reduce distortion during heat treatment.

Hardening
Harden from a temperature of 960-1050^oC followed by water or oil quenching. Hardness after quenching is appr. 52 HRC (water quenching), 47 HRC (oil quenching).

Tempering
Tempering temperature: 560-700^oC.

Nitriding
Possible. Preheating before use: 200-300 ^oC, absolutely necessary.

Tempering Diagram

Click the image to enlarge the diagram.

Forging
Hot forming temperature: 1100-850^oC.

Machinability
No data.

Forms manufactured: Please see the  Dimensional Sales Program.

Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.



Delivery Condition
EAF+LF+VD+(ESR), Hot rolled or Forged, Annealed, EFS, Hardness≤235HB, Un-machined or
Machined surface (Peeled, Turned, Milled, Grinded), UT 100% Passed

Characteristics
Hot work tool steel featuring a fine combination of heat checking resistance, hot strength and impact strength; admits water cooling.

Applications
1. Highly stressed hot work tools, mainly for the processing of heavy alloys, such as mandrels, dies
and containers for metal tube and rod extrusion; hot extrusion tools;
2. Tools for the manufacture of hollows, screws, rivets, nuts and bolts.
3. Die casting tools, forming dies, die inserts, hot shear blades.

Heat Treatment
Annealing
750 to 800°C (1382 to 1472°F)
Slow controlled cooling in furnace at a rate of 10 to 20°C/hr (50 to 68°F/hr) down to approx. 600°C (1112°F), further cooling in air. Hardness after annealing: max. 235 HB.

Stress relieving
600 to 650°C (1112 to 1202°F)
Slow cooling in furnace; intended to relieve stresses set up by extensive machining, or in complex shapes. After through heating, hold in neutral atmosphere for 1 - 2 hours.

Hardening
1010 to 1050°C (1850 to 1922°F)
Oil, salt bath (500 - 550°C / 932-1022°F), air
Holding time after temperature equalization: 15 to 30 minutes.
Obtainable hardness: 52 - 56 HRC

Tempering
Slow heating to tempering temperature immediately after hardening / time in furnace 1 hour for each 20 mm of work piece thickness, but at least 2 hours / cooling in air. It is recommended to temper at least twice. A third tempering cycle for the purpose of stress relieving may be advantageous.
1st tempering approx. 30°C (86°F) above maximum secondary hardness.
2nd tempering to desired working hardness. The tempering chart shows average tempered hardness values.
3rd for stress relieving at a temperature 30 - 50°C (86 to 122°F) be low highest tempering temperature.


What we can offer
What we can offer?

We offer a wide range of steel products in a wide variety of dimensions and executions, acc.to the common international specifications or customerized.
Machining and heat treatment are available.
Also, we advise you in choosing the right materials.

Shape Available
Solid round bar
Flat bar
Square bar
Hexagon bar
Block
Plate
Sheet
Wire rod
Strip





AISI

DIN

JIS

Stock

Application

Hot Work Tool Steel

H11

1.2343

SKD6

√

Die Casting Dies,Extrusion Dies, Hammer Dies,
Ram Dies,
Forging Dies
etc.

H13

1.2344

SKD61

√

H10

1.2365

SKD7



--

1.2367

--



L6

1.2714 / 1.2713

SKT4

√

H12

1.2606

SKD62



H21

1.2581

SKD5

√

Cold Work Tool Steel

D3

1.2080

SKD1

√

Cutting Tools, Punching Tools, Shear Bladers, Reamers, Thread Rolling Dies, Calipers, Sockets etc.

--

1.2601

~SKD11

√

D2

1.2379

~SKD11

√

--

1.2379 MOD

DC53 (Daido)

√

D6

1.2436

--



O1

1.2510

SKS3

√

O2

1.2842

--



A2

1.2363

SKD12



S1

1.2550

--



S7

1.2357

--



--

1.2767

SKT6



L2

1.2210

--



Plastic
Mould Steel

P20

1.2311

--

√

      Mold Base,           Core & Cavity,         Bumper Mold             etc.

P20+Ni

1.2738

--

√

P20+S

1.2312

--

√

--

1.2316

--



420

1.2083

SUS420J2

√

--

--

NAK80 (Daido)

√

Alloy Steel

4120

25CrMo4 / 1.7218

SCM420



Shafts, Gears, Drillers, Chains, Bolts, Nuts, Pins, Suds, Keys, Bites, Crankshafts, Connecting Rods, Came, Couplings  etc.

4135

34CrMo4 / 1.7220

SCM435



4130

34CrMo4 / 1.7220

SCM430

√

4140

   42CrMo4 /        42CrMoS4 /                1.7225

SCM440

√

4142

41CrMo4 / 1.7223

SCM440



4145H

--

--



4330V

--

--



4340

34CrNiMo6 / 1.6582

SNCM439



5115

16MnCr5 / 16MnCrS5 / 1.7131





5120

20MnCr5 / 20MnCrS5 / 1.7147

SMnC420H



5140

41Cr4 / 41CrS4 / 1.7035

SCr440

√

8620

21NiCrMo2 / 1.6523

SNCM220



8640

40NiCrMo2-2 / 1.6546

SNCM240



--

18CrNiMo7-6 / 17CrNiMo6 / 1.6587

--



9840

36CrNiMo4 / 1.6511

--



E71400

41CrAlMo7-10 / 1.8509

SACM1



--

34CrAlNi7 / 1.8550

--



Bearing Steel

E52100

100Cr6 / 1.3505

SUJ2

√

Bearing, Shafts
etc.

--

100CrMn6 / 1.3520

--



--

100CrMo7-3 / 1.3536

--



Spring Steel

5155

55Cr3 / 1.7176

SUP9



Springs

6150

51CrV4 / 1.8159

SUP10



9261

60CrSi7 / 1.7108

--



Carbon Steel

1010

CK10 / C10E / 1.1121

S10C



Shafts, Chains, Bolts, Nuts, Pins, Suds, Keys, Bites, Came, Couplings  etc.

1020

C22 / 1.0402

S20C

√

1040

CK40 / C40E / 1.1186

S40C

√

1045

CK45 / C45E / 1.1191

S45C

√

1050

CK50 / C50E / 1.1206

S50C

√

1055

CK55 / C55E / 1.1203

S55C



1064

CK60 / C60E / 1.1221

S58C



High Speed Tool Steel

M2

1.3343

SKH51

√

Reamer,
      End-mill,
Hob, Cutter, Bite, Drill, Punch, Tap, Brooch
etc.

M7

1.3348

--



M42

1.3247

SKH59

√

M35

1.3243

SKH55

√

T1

1.3355

SKH2



T15

1.3202

--



T42

1.3207

SKH57




Note:
1). √ means we have stoc
2). Delivery Condition:
Smelting: EAF+LF+VD (+ESR)
Making: Hot rolled, Cold rolled, Forged, Cold Drawn
Heat Treatment: Untreated, Annealing, N+T, Q+T
Surface: Black, Peeled, Turned, Milled, Grinded, Polished
