• Model NO.：KM-801
• Special Use：Wear Resistant Steel
• Stock：Not Stock
• Width：10mm~3500mm
• Length：2m,3m,6m,8m,12m, or as Required.
• Surface：Varnished,PE Coated,Galvanized.
• MOQ：1000kgs
• Price Term：Ex-Work,Fob,CIF,CFR,etc.
• Delivery Time：Prompt Delivery, or as Order′s Quantity.
• Transport Package：Standard Export Seaworthy
• Specification：Thickness: 0.3mm~500mm
• Trademark：KINGMETAL
• Origin：China
• Production Capacity：300 Ton,Month

 Grade :S420M S420ML S460 S460NL (1.8903) Specification:Thickness 8mm-300mm, Width: 1500-4020mm, Length: 3000-27000mmStandard:EN10025-3 : 2004   Technical delivery conditions for normalized/normalized rolled weldable fine grain structural steelsApproval By Third PartyABS, DNV, GL, CCS, LR , RINA, KR, TUV, CEClassification:Normalized rolled weldable fine grain structural steelsEquivalent grades:S420M S420ML S460 S460NL
Chemical composition % of the Product analysis of grade S460NL (1.8903)

Nominal thickness =< 63(mm) CEV max = 0.53
Nominal thickness from 63 to 100 (mm) CEV max = 0.54
For long products the P and S content can be 0.005% higher
For railway application a maximum S content of 0.01% may be agreed at the time of enquiry and order
If sufficient other N-binding elements are present the minimum total Al content does not applay
Cu content above 0.4% may cause hot shortness during hot formingCSiMnNiPSCrMoVNbTimax 0.22max 0.650.95 - 1.8max 0.85ma 0.035max 0.03max 0.35max 0.13Max 0.22max 0.06max 0.06

Equivalent grades of grade S460NL (1.8903)

Germany
DIN,WNrFrance
AFNOREngland
BSItaly
UNIChina
GBRussia
GOSTTStE460E 460 FP55EEFe E 460 KT N
