• Shape Type：Steel Coil, Hot-Galvanized Steel Coil
• Coil ID：508 mm,610 mm
• Zinc Coating：30-275G,M2
• Hardness：Hard
• Color：Customized
• Sample：Free
• MOQ：1ton
• Price Term：CIF ,CFR ,Fob, Ex-Work
• Surface：Coated, Clean, Blasting,Galvanized
• Tolerance：1%, 2%, 3%, Customize
• Thickness：0.1mm-300mm or as Requied
• Width：0.6-3m or as Required
• Length：4-12m or as Required
• Stock：Stock
• Edge：Slit edge
• Application：Container Plate
• Model NO.：SGCC,SGCD,DX51D
• Processing Services：Welding Punching Cutting Decoiling
• Transport Package：Standard Seaworthy Export Packing
• Specification：As Your Requirement
• Trademark：ZHONGHENG
• Origin：Shandong
• HS Code：7210490000
• Production Capacity：60000tons,Year

Product Description

   Color-coated coils are based on hot-dip galvanized sheet, hot-dip galvanized sheet, electro-galvanized sheet, etc. After surface pretreatment (chemical degreasing and chemical conversion treatment), one or several layers of organic coatings are applied on the surface, and then A product that has been cured by baking. It is named after the color steel coils coated with organic coatings of various colors, referred to as color coated coils.
The color-coated steel strip using hot-dip galvanized steel strip as the base material is protected by the zinc layer, and the organic coating on the zinc layer plays a covering and protective role to prevent the steel strip from rusting, and the service life is longer than that of the galvanized strip. 1.5 times.
   Color-coated coils are light, beautiful and have good anti-corrosion properties, and can be directly processed. The colors are generally divided into gray-white, sea-blue and brick red. They are mainly used in advertising, construction, household appliances, electrical appliances, furniture and transportation. Industry.
The paint used in the color-coated coil selects the appropriate resin according to the use environment, such as polyester silicon modified polyester, polyvinyl chloride plastisol, polyvinylidene chloride, etc. Users can choose according to the purpose.

Classification
   Hot dip galvanized substrate
The product obtained by coating the organic coating on the hot-dip galvanized steel sheet is the hot-dip galvanized color-coated sheet. In addition to the protective effect of zinc, the organic coating on the surface of the hot-dip galvanized color-coated sheet also plays the role of insulation and protection, preventing rust, and the service life is longer than that of the hot-dip galvanized sheet. The zinc content of the hot-dip galvanized substrate is generally 180g/m2 (double-sided), and the maximum galvanized amount of the hot-dip galvanized substrate for building exterior is 275g/m2.
   Hot-dip Al-Zn substrate
The hot-dip galvanized steel sheet (55% Al-Zn) is used as the new coating substrate, and the content of aluminum and zinc is usually 150g/m2 (double-sided). The corrosion resistance of hot-dip galvanized sheet is 2-5 times that of hot-dip galvanized sheet. Continuous or intermittent use at temperatures up to 490°C will not severely oxidize or produce scale. The ability to reflect heat and light is 2 times that of hot-dip galvanized steel, and the reflectivity is greater than 0.75, which is an ideal building material for energy saving.
   Electro-galvanized substrate
The electro-galvanized sheet is used as the substrate, and the product obtained by coating the organic paint and baking is the electro-galvanized color-coated sheet. Because the zinc layer of the electro-galvanized sheet is thin, the zinc content of the electro-galvanized sheet is usually 20/20g/m2, so this product is not suitable for use. Make walls, roofs, etc. outdoors. But because of its beautiful appearance and excellent processing performance, it can be mainly used in home appliances, audio, steel furniture, interior decoration, etc.
   Polyester (PE)
Good adhesion, rich color, wide range in formability and outdoor durability, medium chemical resistance, low cost.
Silicon modified polyester
   Namely (SMP), the coating film has good hardness, abrasion resistance and heat resistance, as well as good external durability and chalk resistance, gloss retention, average flexibility, and moderate cost.
High Durability Polyester
   Namely (HDP), excellent color retention and UV resistance, excellent outdoor durability and chalk resistance, good film adhesion, rich color, excellent cost performance.
Polyvinylidene fluoride
   Namely (PVDF), excellent color retention and UV resistance, excellent outdoor durability and chalk resistance, excellent solvent resistance, good formability, dirt resistance, limited color, high cost

    PPGI is the abbreviation of Pre-Painted Galvanized, that is, color-coated galvanized.
Usually refers to PPGI Coil (color-coated galvanized coil), PPGI Sheet (color-coated galvanized sheet) and other steel products.
It is based on the galvanized coil with a certain technology and then covered with colored paint to give the product more colors, and this colorful and beautiful surface makes it more widely used.

Product Parameters
