• Trademark：BAO STEEL TAI STEEL MA STEEL
• Specification：Width 100-3000mm
• Model NO.：P265GH
• Production Capacity：500000kgs

GradeCSiMnPSAl(min)NP265GH0.200.400.80-1.400.0250.0150.0200.012CrCuMoNbNiTiV0.300.300.080.0200.300.030.02

P265GH Mechanical Property

 GradeThicknessYieldTensilmieElongationImpact Energy(KV J) minP265GHmmMin MpaMpaMin %-20°0°+20°≤ 16265410-5302227344016> to ≤40255410-5302227344040> to ≤60245410-5302227344060> to ≤100215410-53022273440100> to ≤150200400-53022273440150> to ≤250185390-530222734

40

Q235qc,Q345qc,Q370qc,Q420qc,Q345qDNH,Q370qDNH,A709-50F-2,A709-50T-2

We offer EN10028 P265GH Boiler Pressure Vessel steel plate and sheet :

1.Chemical Composition:

C :≤0.2 Si:≤ 0.4 Mn:0.8-1.4 S :≤0.015 N:≤ 0.012 AL:≤ 0.02 Nb:≤ 0.02

P :≤0.025 Cr:≤0.30 Ni:≤0.30 Mo::≤ 0.08 Cu:≤ 0.30 V:≤ 0.02 Ti :≤ 0.03

2. Mechanical properties:

Tensile Strength σb(MPa) :

410-530 (thickness under 100mm);

400-530(thickness between 100-150mm);

390-530(thickness between 150-250mm)

Yield Strength σ0.2 :

≥265(thickness under 16mm);

≥255(thickness between 16-40 mm);

≥245(thickness between 40-60mm);

≥215(thickness between 60-100mm);

≥200(thickness between 100-150mm);

≥185(thickness between 150-250mm)

Elongation δ5(%) : ≥ 22

Impact Energy (KV J) :

≥27(under -20 degree );

≥34(under 0 degree );

≥40(under 20 degree )

3. Application :

EN10028 P265GH steel plates is a kind of material for boiler and pressure vessel steel. EN10028 P265GH steel plates is characterised by a minimum yield strength of 185 - 265 MPa and by good weldability,so P265GH steel is mainly used to for manufacturing boilers, pressure vessels and pipes transporting hot liquids.
