• Trademark：ZJDP
• Specification：GB, ASTM, ASME, EN, DIN, JIS
• Transport Package：Woven Bags, Plastic Bags, Cap Ends, Plywood Cases
• Model NO.：2205, S81803
• Origin：China
• Production Capacity：23000ton,Year

NameStainless steel pipe tube316Ti-chemical composition %
 C                      Mn            P                  S                 Si                 Cr                   Ni                    Mo                Ti
0.03 max   2.00 max   0.045 max   0.030 max  0.75 max    16.0-18.0      10.0-14.0      2.00-3.00    5*(C+N)-0.70316Ti-mechanical
Properties
(ASTM A269)Tensile Strength         Yield Strength            Elongation                     Hardness
min Kis                        min Kis                      in 2 in. or 5 mm              max
Mpa                             Mpa                           min  %                            HRB
515                              205                              35                                   90     Supply Capacity15000 MT/YearSteel gradeTP201, TP 202, TP 301, TP 302, TP 303,TP 304, TP 304L, TP310S, TP309S,TP316,TP316L, TP316Ti TP317,TP317L,TP321,TP347, TP347H,TP410,TP430,TP901L,TP904LExecutive StandardGB/T14976-2002,GB/T14975-2002
ASTM/ASME A312/SA312,ASTM/ASME A269/SA269,ASTM/ASME A213/SA213,
DIN 17440,DIN 17456-85,JIS G 3459,JIS G 3463,JIS G 3448 JIS G 3446.Outside diameter6mm-610mmWall thickness0.6mm-30mmLength1M-13M according to the requiremet of customersTolerance of
Dimensions
(ASTM A269)Outerside Diameter       Tolerance of Outerside    Toleerance of Wall
in[mm]                   Diameter,in[mm]           Thickness,%
1/4-1/2[6.35-12.7]          ±0.005[0.13]                 ±15
1/2-1 1/2[12.7-38.1]        ±0.005[0.13]                 ±10
1 1/2-3 1/[38.1-88.9]       ±0.010[0.25]                 ±10
3 1/2-5 1/2[88.9-139.7]     ±0.015[0.38]                 ±10
5 1/2- 8[139.7-203.2]       ±0.030[0.76]                 ±10TestChemical Analysis.
Hydrostatic or Nondestructive Electric Test,
Intergranular Corrosion Test,
Flaring Test,
Flattening Test,
Flange Test,
Grain Size Test,
and so onCertificate ISO9001:2008,PED,SGS,and so on Technique Cold Rolled,Hot Rolled, Cold/Hot Rolled,Cold Drawn, Surface treatment AP,BA,Plolished,according to the customer's requirements.PackingWooden case,PVC packing, Plywood case,wooden pallet,and others standard export packingApplication   Chemical industries
   Pulp&paper making machine
   Coastal architectural paneling, railings & trim
   Heat exchangers,condensers,evaporation equipments.
   Food,drink,beer making machine includ container and transportation.
   Oil&gas industries
   Dyeing industries
 Payment30% T/T payed in advanced,the balance should be payed against the copy of B/L
