H Beam Automatic Fabrication Machine Hj15-S
TANG CHENG INTERNATIONAL TRADE CO., LTD.- Flange Thickness：6-40mm
- Flange Width：200-800mm
- Web Thickness：6-32mm
- Web Height：200-1500mm
- Grade：Q235
- Speed：0.35-3m,Min
Base Info
- Dimension：38000*4000*4200mm
- Total Power：140kw
- Welding：Saw,MIG
- Model NO.：HJ15-S
- Origin：China
Description
Basic Info.
Model NO. HJ15-S Welding Saw/MIG Total Power 140kw Dimension 38000*4000*4200mm Origin ChinaProduct Description
Technical parameters
- Single wire
- Work piece material: Q235A/Q345A
- Web height: 200-1500mm
- Web thickness: 6-32mm
- Flange width: 200-800mm
- Flange thickness: 6-40mm
- Speed: 0.35-3m/min
- Welding: SAW/MIG
- Total power: 140kW
- Dimension (length×width×height) :
38000×4000×4200mm
Goods supply range
• Main machine
