• Origin：China
• Trademark：YONG YANG
• Specification：54E1, 60E1
• Transport Package：Bare in Bundles by Steel Wire
• Model NO.：UIC54, UIC60, 54E1, 60E1
• HS Code：730210
• Production Capacity：200000ton,Year

SizeDimension(mm)Weight (kg/m)MaterialLength (m)Head WidthBottom WidthHeightThicknessUIC54701401591654.77900A/110012-25UIC6074.315017216.560.2160 E17215017216.560.21R200      R220      R260
R350HT12-2560 E27215017216.560.0312-25



- Standard of UIC 860 V: 1996 - prescribed four types pearlite steel rails in the range of tensile strength from 700 to 1300 MPa.

- Standard EN 13674-1:2011, provides seven types pearlite steel hardness in the range 200 to 390 HBV, types steel in accordance with EN 13674, based on the values of hardness (R 200, R 220, R 260, R 260 Mn, 320 Cr, 350 HT, 350 LHT).

AS the leading manufacturer of steel rails in China, Our company can design and develop various products of steel rails using high quality raw materials by implementing latest technology and advanced techniques, which meets the international UIC standards.
