UL Fire Protection Fighting Pipes Tuberias Contra Incendios
Weifang East Pipe Industry Technical Co., Ltd.- Usage：Pipeline Transport, Chemical Industry, Construction & Decoration, Special Purpose
- Surface Treatment：Painted
- Material：Carbon Steel
- Technique：ERW Saw Hot Rolled Cold Drawn
- Type：Welded or Seamless
- Section Shape：Round
Base Info
- Specification：FM UL
- Transport Package：Bundle
- Surface：Painted
- Zinc Content：99.9999%
- End：Groove or Plain,Bevel,Thread,Flange
- Fittings：Coupling, Elbow, Tee, Cross, Flange, Valve,Reducer
- Length：5800mm ,6500mm
- W.T：2.11-10.31
- O.D.：21.3-323.9
- Model NO.：fire fighting steel pipe
- Trademark：EAST
- Origin：Shandong China
- HS Code：7308900000
- Production Capacity：50000tons,Year
Description
N.D.O.D. SCH 10 SCH 30/40 W.T. NORMAL WEIGHT W.T. NORMAL WEIGHT (mm) (INCH) (mm) (inch) (mm) (inch) (kg/mtrs) (lbs/ft) (mm) (inch) (kg/mtrs) (lbs/ft) 15 1/2'' 21.30 0.840 ---- ---- ---- ---- 2.77 0.109 1.27 0.85 20 3/4'' 26.70 1.050 2.11 0.083 1.28 0.96 2.87 0.113 1.69 1.13 25 1'' 33.40 1.315 2.77 0.109 2.09 1.41 3.38 0.133 2.50 1.68 32 1.1/4'' 42.20 1.660 2.77 0.109 2.69 1.81 3.56 0.140 3.39 2.27 40 1.1/2'' 48.30 1.900 2.77 0.109 3.11 2.09 3.68 0.145 4.05 2.72 50 2'' 60.30 2.375 2.77 0.109 3.93 2.64 3.91 0.154 5.45 3.66 65 2.1/2'' 73.00 2.875 3.05 0.120 5.26 3.53 5.16 0.203 8.64 5.80 80 3'' 88.90 3.500 3.05 0.120 6.46 4.34 5.49 0.216 11.29 7.58 90 3.1/2'' 101.60 4.000 3.05 0.120 7.41 4.98 5.74 0.226 13.58 9.12 100 4'' 114.30 4.500 3.05 0.120 8.37 5.62 6.02 0.237 16.09 10.80 125 5'' 141.30 5.563 3.40 0.134 11.58 7.78 6.55 0.258 21.79 14.63 150 6'' 168.30 6.625 3.40 0.134 13.85 9.30 7.11 0.280 28.29 18.99 200 8'' 219.10 8.625 4.78 0.188 25.26 16.96 7.04 0.277 36.82 24.72 250 10'' 273.10 10.750 4.78 0.188 31.62 21.23 7.08 0.307 51.05 34.27
160.203 5.16 27.22 28.85 8.30 8.79 -- 850 60 1000 70 0.219 5.56 29.28 31.04 8.92 9.46 -- 910 64 1070 75 0.322 8.18 42.55 45.10 12.97 13.75 40 1340 94 1570 110
ASTM A135 (BLACK AND GALVANIZED) SCH40
16
| N.D. | O.D. | WALL THICKNESS | NOMINAL WEIGHT | TEST PRESSURE |
| inch | mm | mm | kg/m | Mp |
| 3/4 | 26.8 | 2.11 | 1.28 | 17.24 |
| 1 | 33.5 | 2.77 | 2.09 | 17.24 |
| 1-1/4 | 42.2 | 2.77 | 2.70 | 16.55 |
| 1-1/2 | 48.3 | 2.77 | 3.10 | 14.48 |
| 2 | 60.3 | 2.77 | 3.93 | 11.72 |
| 2-1/2 | 73.0 | 3.05 | 5.26 | 10.34 |
| 3 | 88.9 | 3.05 | 6.45 | 8.27 |
| 3-1/3 | 101.6 | 3.05 | 7.41 | 6.89 |
| 4 | 114.3 | 3.05 | 8.36 | 6.21 |
| 5 | 141.3 | 3.40 | 11.58 | 5.86 |
| 6 | 168.3 | 3.40 | 13.84 | 5.02 |
| 8 | 219.1 | 4.80 | 15.41 | 4.26 |
ASTM A135 (BLACK AND GALVANIZED) SCH40
| N.D. | O.D. | WALL THICKNESS | NOMINAL WEIGHT | TEST PRESSURE |
| inch | mm | mm | kg/m | Mp |
| 1/2 | 21.3 | 2.77 | 1.27 | 17.20 |
| 3/4 | 26.8 | 2.87 | 1.68 | 17.20 |
| 1 | 33.5 | 3.38 | 2.50 | 17.20 |
| 1-1/4 | 42.2 | 3.56 | 3.38 | 17.20 |
| 1-1/2 | 48.3 | 3.68 | 4.05 | 17.20 |
| 2 | 60.3 | 3.91 | 5.43 | 16.08 |
| 2-1/2 | 73.0 | 5.16 | 8.62 | 17.20 |
| 3 | 88.9 | 5.49 | 11.28 | 15.30 |
| 3-1/3 | 101.6 | 5.74 | 13.56 | 14.00 |
| 4 | 114.3 | 6.02 | 16.06 | 13.06 |
| 5 | 141.3 | 6.55 | 21.76 | 11.50 |
| 6 | 168.3 | 7.11 | 28.34 | 10.48 |
| 8 | 219.1 | 8.18 | 36.90 | 7.96 |
