• Usage：Boiler Pipe
• Section Shape：Round
• Od：8mm-219mm
• Wt：2mm-40mm
• Steel Grade-1：T1,T2, T11, T12, T22, T23, T91,T92, SA210c SA210A1
• Steel Grade-2：10crmo5-5 13crmo4-5 10crmo9-10 X10crmovnb9-1
• Steel Grade-3：20g,25mng 15crmog 12cr1movg ,R102
• Production Standard：ASME SA210, ASME SA213, En10216-2:2002, GB 5310
• Loading Port：China Main Port
• Transport Package：in Wooden Case, Woven Bag or as Request
• Specification：ASTM, JIS, BS, DIN, GOST
• Trademark：Kingmetal
• Origin：Made in China
• HS Code：730490
• Production Capacity：1000ton,Month

Basic Info.

Usage Boiler Pipe Section Shape Round Od 8mm-219mm Wt 2mm-40mm Steel Grade-1 T1/T2/ T11/ T12/ T22/ T23/ T91/T92, SA210c SA210A1 Steel Grade-2 10crmo5-5 13crmo4-5 10crmo9-10 X10crmovnb9-1 Steel Grade-3 20g/25mng 15crmog 12cr1movg /R102 Production Standard ASME SA210, ASME SA213, En10216-2:2002, GB 5310 Loading Port China Main Port Transport Package in Wooden Case, Woven Bag or as Request Specification ASTM, JIS, BS, DIN, GOST Trademark Kingmetal Origin Made in China HS Code 730490 Production Capacity 1000ton/Month

Product Description

En10216-2 P195GH 1.0348 Alloy Seamless Boiler Tube


EN 10216-2 Seamless steel tubes for pressure purposes - Technical delivery conditions - part 2: Non- alloy and alloy steel tubes with specified elevated temperature

This Part of EN10216 specifies the technical delivery conditions in two categories for seamless tubes of circular cross section, with specified elevated temperature properties, made of non-alloy and alloy steel.

Steel Grade: P195GH  Steel Number: 1.0348

Chemical composition (cast analysis)^a, in % by mass

C: ≤0.13

Si: ≤0.35

Mn: ≤0.70

P max: 0.025

S max: 0.020

Cr:≤0.30

Mo: ≤0.08

Ni: ≤0.30

Al total: ≥0.020^b

Cu: ≤0.30 ^c

Nb: ≤0.010^d

Ti: ≤0.040^d

V: ≤0.02_d

Cr+Cu+Mo+Ni: ≤0.70
