Color Coated Steel Coil (Galvanized, galvalume base metal)
CHANGZHOU DINGANG METAL MATERIAL CO., LTD.- Standard：ASTM, JIS, GB
- Surface Treatment：Coated
- Technique：Cold Rolled
- Application：Walls, Roofing
- Edge：Mill
- Stock：Not Stock
Base Info
- Model NO.：DX51D+Z
- Grade：CGCC, Cgcd, Cglcc, Cglcd
- Thickness：0.18-1.5mm
- Width：30-1250mm
- Surface Finish Color：Ral
- Coating Thickness：50-225GSM
- Inside Diameter：508mm
- Weight/Coil：3-8tons
- Sample：Available
- Delivery：15-35days After Receipt Deposit
- Payment：30%Prepaid, 70% See Copy of B,L
- Transport Package：Standard Export Packing
- Specification：JIS G 3312
- Trademark：Dingang or as Customer′s request
- Origin：China
- HS Code：72107000
- Production Capacity：300, 000tons,Year
Description
Coat
TypeDope Type Coat
Thickness
(μm) Rigidity
Of Pencil Shine 60°(%) Bend Return
Impact(J) Salt Spray
Tolerance(H) High Middle Low Thickness≤0.75mm
(Steel window≤0.8
mm) 180°T Thickness>0.75
mm(Steel
window>0.80mm) A B Second
Coat PE ≥20 ≥F >70 40-70 <40 ≤3T ≤5T 90° ≥9 ≥500 SMP ≥20 ≥F >70 40-70 <40 ≤3T ≤5T 90° ≥9 PVDF ≥20 ≥F -- 40-70 <40 ≤2T ≤5T 90° ≥9 ≥1000 Plastisol ≥100 -- -- 40-70 <40 ≤1T ≤5T 90° ≥9 First PE ≥10 ≥HB >70 40-70 <40 ≤3T ≤5T 90° ≥9 ≥250
Welcome contact me
Trista Yang
Mobile: 0086 15189756323
Type
Thickness
(μm)
Of Pencil
Impact(J)
Tolerance(H)
(Steel window≤0.8
mm) 180°T
mm(Steel
window>0.80mm)
Coat
Welcome contact me
Trista Yang
Mobile: 0086 15189756323
