Incoloy Tube 825 Corrosion Resistant Alloy Uns 08825
Huzhou Dapu Stainless Steel Co., Ltd.- Type：Stainless Steel Pipes
- Standard：ASTM, AISI, GB, JIS, DIN, EN
- Grade：Incoloy
- Certification：ISO, RoHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
- Shape：Round
- Technique：Cold Rolled
Base Info
- Surface Treatment：Polishing, Pickling, Annealing
- Outside Diameter：4mm - 914.4mm;8mm-630mm
- Wall Thickness：0.6mm - 30mm;0.5mm-45mm
- Length：5.8-6.1 M or as Customers′ Request
- Inspection：Dekra,TUV
- Transport Package：Plastic Bag in Bundles or Seaworthy Wooden Case
- Trademark：DEIPOO
- Origin：China
- HS Code：7304419000
- Production Capacity：3000ton,Year
Description
Basic Info.
Surface Treatment Polishing, Pickling, Annealing Outside Diameter 4mm - 914.4mm;8mm-630mm Wall Thickness 0.6mm - 30mm;0.5mm-45mm Length 5.8-6.1 M or as Customers′ Request Inspection Dekra,TUV Transport Package Plastic Bag in Bundles or Seaworthy Wooden Case Trademark DEIPOO Origin China HS Code 7304419000 Production Capacity 3000ton/YearProduct Description
1. Specification: (Φ 6mm-Φ 610mm), wall-thickness(0.6mm-30mm).
2. Standard: GB, ASTM(ASME), EN, DIN, JIS and other international standard.
3. Surface treatment: Pickling, annealing, polishing.
4. Productivity: 500ton/Month.
Annealing condition:
Annealed condition: cold-worked annealed
| Tensile Strength, min, MPa: | 586 |
| Yield Strength (0,2% offset), min, MPa: | 241 |
| Elongation in 2 in. or 50 mm ( or 4 D), min, %: | 30 |
Annealing condition:
Annealed condition: hot-forming quality (hot-finished or cold-drawn annealed)
| Tensile Strength, min, MPa: | 586 |
| Yield Strength (0,2% offset), min, MPa: | 241 |
| Elongation in 2 in. or 50 mm ( or 4 D), min, %: | 30 |
Chemical Analysis
| Ni | = 38% -46% | Fe | = 22,00% min |
| Cr | = 19,50% - 23,50% | Mo | = 2,50% - 3,50% |
| Cu | = 1,50% - 3,00% | Mn | = 1,00 max |
| Ti | = 0,60% - 1,20% | Si | = 0,50% max |
| Al | = 0,20% max | C | = 0,05% max |
| S | = 0,03% max |
