• Model NO.：IR-C
• Outer Diameter：18mm~416mm
• Wall Thickness：0.8mm~20mm
• Length：6meters, 9meters, 12meters, Random Length
• Surface：Annealed, Pickling, Straightening
• Tolerance of Size：+,- 0.05mm
• Transport Package：Bundled, Wrapped, Wooden Cased.
• Specification：GB,T8163, JIS, DIN
• Trademark：Iron&steel
• Origin：China
• HS Code：73041990
• Production Capacity：100 Tons Per Month

DesignationSymbolDescriptionCold finished (hard)BKTubes do not undergo heat treatment following the final cold forming and, thus, have a rather high resistance to deformationCold finished (soft)BKWThe final heat treatment is followed by cold drawing involving limited deformation. Appropriate further processing allows a certain degree of cold forming(e. G. Bending expanding). Cold finished and stress-rellevedBKSHeat treatment is applled following the last cold forming process. Subject to appropriate processing conditions, the increase in the residual stresses involved enables both forming and machining to a certain degreeAnnealedGBKThe last cold forming process is followed by annealing in a controlled atmosphereNormalizedNBKThe last cold forming process is followed by annealing above the upper transformation point in a controlled atmosphere
MaterialChemical composition (%)CMnPSSiNiCu20#
AISI 10200.17~0.230.35~0.65≤0.035≤0.0350.17~0.37≤0.3≤0.2545#
ASTM1045, DIN450.42~0.50.5~0.8≤0.04≤0.0450.17~0.37≤0.25≤0.25Mechanical Properties of seamless steel pipe Steel materialTensile Strength MPaYield strength MPaElongation
%HardnessStraightness20#≥510≥245≥25≤156HB0.3~1.045#≥647≥355≥16≤HRC620.3~1.
