• Model NO.：Q690 high strength steel plate
• Leading Time：10-25days
• MOQ：1tons
• Transport Package：Waterproof and Plastic Package
• Specification：20mm
• Trademark：wusteel
• Origin：Henan
• HS Code：2201
• Production Capacity：50000tons

Package

Water proof paper+metal pallet+Angle bar protection+steel belt or as requirements.
The inner size of container is below:
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM,23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM,27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM,27MTS

Payment term

L/C at sight or 30% TT as deposit and the balance paid against copy of B/L

Steel Grade:  A514GrA, A514GrB, A514GrE, A514Gr F, A514Gr H, A514Gr P, A514Gr Q, and A514Gr S

Thickness range Yield strength Min Tensile strength hardness
A514 grade B:  5mm-40mm 100ksi (690MPa) 110-130ksi
A514 grade A:  5mm-40mm 100ksi (690MPa) 110-130ksi

A514 grade E:  5mm-215mm 100ksi (690MPa) 110-130ksi
A514 grade F:  5mm-80mm 100ksi (690MPa) 110-130ksi
A514 grade H:  5mm-80mm 100ksi (690MPa) 110-130ksi
A514 grade P:  5mm-215mm 100ksi (690MPa) 110-130ksi

A514 grade Q: 5mm-215mm 100ksi (690MPa) 110-130ksi
A514 grade S: 5mm-80mm 100ksi (690MPa) 110-130ksi

Thickness Above 65mm, we can still provide products with min yield strength 100ksi (690MPa), the product name should be A514 Grade [X] Mod., such as you can order A514 grade Q with thickness of 177.8mm, and yield strength is above 100ksi, so product name should be A514 grade Q Mod.,With A514Gr.Q,

we provide ABS certification with Max thickness 215mm, steel plate Max. unit weight 32Tons,And intended to

use in rig rack, such as Ju2000 rig, and other offshore engineering.
Thicknesses range from 5mm to 8mm in widths 2000mm to 2500mm, Maximum length is based on load and

unload , and transport conditions, from 6000mm to 12000mm.Thicknesses range above 10mm, in widths from

2000mm to 3500mm,Max. unit weight 32 tons,(plate thickness above 70mm will be rolled with ingot casting)
Please inquire for other sizes and detailed information please let us know.



1. Are you trading company or manufacturer ?
We are both Manufaturer and trading company, we have professional processing mill with 11 years' experience and have took part in trading for 25 years.
2. How about your quality and how do you guarantee the quality?
All products we supply is primary as you need, Our company is certificated to ISO9001:2008, and every product will be tested for 4-5 processes. We welcome customers or the third party inspection agencies to come to our factory for inspection.
3. Do you provide samples ? Is it free or extra ?
Yes, we could offer the sample for free charge but freight cost shall be paid by your Party.
4. How long is your delivery time?
For Stocks, we can send the goods to loading port wiyhin 7 days after receiving the deposit ;
For production period, it usually needs about 25 days ~45 days after receiving the deposit.
5. What is your terms of payment ?
Usually 30% deposit by TT in advance and balance against copy pf BL or L/C at sight .
