• Model NO.：410
• Transport Package：Wooden Pallet
• Specification：1220*2440, 1500*3000, 1500*6000, 2000*6000mm
• Trademark：TISCO BAO STEEL
• Origin：China
• HS Code：7219340000
• Production Capacity：500000kgs

410 stainless steel Chemical Composition

Element

Percent by Weight

C

Carbon

0.15 max

Mn

Manganese

1.00 max

Si

Silicon

1.00 max

Cr

Chromium

11.50 - 13.50

C

Nickel

0.75 max

S

Sulfur

0.03 max

P

Phosphorus

0.04 max

The values reported below are typical for Type 410 alloy in the annealed condition.

• Density: 0.276 lb/in3

• Specific Gravity: 7.65

• Melting Range: 2700-2790°F 1482-1532°C

• Modulus of Elasticity: 29 x 106 psi (200 GPa)

410 stainless steel Coefficient of Thermal Expansion

Temperature Range

Coefficients

°C

°F

cm/cm/°C

in/in/°F

20-200

68-392

10.5 x10-6

5.9 x 10-6

20-600

68-1112

11.6 x 10-6

6.5 x 10-6

410 stainless steel Thermal Conductivity

Temperature Range

W/m·K

Btu/(hr · ft · °F)

°C

°F

100

212

(0.249)

14.4

410 stainless steel Specific Heat

• .11 Btu/lb.·°F

410 stainless steel Electrical Resistivity

Temperature Range

microhm-cm

°C

°F

20

68

56

Typical Annealed Properties

Hardening Response HRC

HRB

0.2% Offset
Yield Strength
Ksi (MPa)

Tensile Strength
Ksi (MPa)

Elongation, Percent in 2" (51 mm)

82-96

30 (205) - 42 (290)

65 (450) - 74 (510)

20 -34

38-45

410 stainless steel Common Trade Names

• ATI 410 (™ Allegheny Technologies)

• Alloy 410

• AISI Type 410

410 stainless steel Common Applications

• Aerospace structures

• Automotive exhausts, manifolds and high temperature engine components

• Medical instruments and devices

• Petro-chemical applications

• Cutlery, kitchen utensils

• Flat springs

• Hand tools
