- Model NO.：KM-221
- Size：6-60mm
- Wt：1-12mm
- Length：1m-12m
- Packaging Detail：Standard Sea-Worthy Package
- Loading Port：Chinese Main Port
- Delivery Time：30 Days Ex Mill
- Connection Type：Flange , Thread , Welded
- Corrugated Type：Annular or Helical
- Certification：ISO,CE
- Transport Package：Standard Sea-Worthy Package
- Specification：6-60mm
- Trademark：Kingmetal
- Origin：Chinese Main Port
- Production Capacity：2000 Ton,Tons , Month
| Test pressure | Burst |
| bend radius | pressure | pressure | bend radius | pressure | pressure |
| Inch | mm | mm | mm | bar | bar | bar | mm | mm | bar | bar | bar |
| 1/4 | 6 | 25 | 100 | 154 | 230 | 616 | 25 | 100 | 246 | 369 | 984 |
| 3/8 | 10 | 40 | 150 | 105 | 157 | 420 | 40 | 150 | 168 | 252 | 672 |
| 1/2 | 12 | 50 | 200 | 88 | 132 | 352 | 50 | 200 | 140 | 210 | 560 |
| 5/8 | 16 | 50 | 200 | 73 | 109 | 292 | 50 | 200 | 116 | 174 | 464 |
| 3/4 | 20 | 70 | 200 | 64 | 96 | 256 | 70 | 200 | 102 | 153 | 408 |
| 1 | 25 | 90 | 200 | 50 | 75 | 200 | 90 | 200 | 80 | 120 | 320 |
| 1¼ | 32 | 110 | 250 | 42 | 63 | 168 | 110 | 250 | 67 | 100 | 268 |
| 1 ½ | 40 | 130 | 250 | 32 | 48 | 128 | 130 | 250 | 51 | 76 | 204 |
| 2 | 50 | 175 | 350 | 31 | 46 | 124 | 175 | 350 | 49 | 73 | 196 |
| 2 ½ | 65 | 200 | 410 | 26 | 39 | 104 | 200 | 410 | 41 | 61 | 164 |
| 3 | 80 | 205 | 450 | 18 | 27 | 72 | 205 | 450 | 28 | 42 | 112 |
| 4 | 100 | 230 | 560 | 16 | 24 | 64 | 230 | 560 | 26 | 39 | 104 |
| 5 | 125 | 280 | 660 | 16 | 24 | 64 | 280 | 660 | 25 | 37 | 100 |
| 6 | 150 | 320 | 815 | 12 | 18 | 48 | 320 | 815 | 20 | 30 | 80 |
| 8 | 200 | 435 | 1015 | 10 | 16 | 40 | 435 | 1015 | 16 | 24 | 64 |
| 10 | 250 | 560 | 1220 | 6.5 | 10 | 26 | 560 | 1220 | 10.5 | 16 | 42 |
