H Beam I Beam
Shandong Zayi Steel Co., Ltd- Grade：Q235
- Standard：AISI, JIS, ASTM, DIN, BS, GB
- Certification：IS0, RoHS, UL, ABS
- Breadth or Width：100~300mm
- Web Thickness：6~20mm
- Length：6m 12m
Base Info
- Model NO.：H beam I beam
- Transport Package：in Bundles
- Specification：100*100*6*8
- Trademark：Shandong Zayi
- Origin：China
- HS Code：7228709000
- Production Capacity：50000 Tons,Month
Description
Standard H beam In StockSize(mm) Weight per meter(kg/m) Size(mm) Weight per meter(kg/m) Size(mm) Weight per meter(kg/m) Size(mm) Weight per meter(kg/m) Size(mm) Weight per meter(kg/m) 100*100*6*8 17.2 294*200*8*12 57.3 428*407*20*35 284 100*63*4.5 11.261 320*134*13.5 62.765 125*125*6.5*9 23.8 294*302*12*12 85 440*300*11*18 128 120*74*5 13.987 360*136*10 60.037 148*100*6*9 21.4 298*149*5.5*8 32.6 446*199*8*12 66.7 140*80*5.5 16.89 360*138*12 65.689 150*75*5*7 14.3 300*150*6.5*9 37.3 450*200*9*14 76.5 160*88*6 20.513 360*140*14 71.341 150*150*7*10 31.9 300*300*10*15 94.5 482*300*11*15 115 180*94*6.5 24.143 400*142*10.5 67.598 175*90*5*8 18.2 300*305*15*15 106 488*300*11*18 129 200*100*7 27.929 400*144*12.5 73.878 175*175*7.5*11 40.4 340*250*9*14 79.7 496*199*9*14 79.5 200*102*9 31.069 400*146*14.5 80.158 194*150*6*9 31.2 344*348*10*16 115 500*200*10*16 89.6 200*110*7.5 33.07 450*150*11.5 80.42 198*99*4.5*7 18.5 346*174*6*9 41.8 582*300*12*17 137 220*112*9.5 36.542 450*152*13.5 87.485 200*100*5.5*8 21.7 350*175*7*11 50 588*300*12*20 151 250*116*8 38.105 450*154*15.5 94.55 200*200*8*12 50.5 350*350*12*19 137 594*302*14*23 175 280*122*8.5 43.492 560*166*14.5 115.108 200*204*12*12 56.7 390*300*10*16 107 596*196*100*15 95.1 280*124*10.5 47.888 560*170*16.5 123.9 244*175*7*11 44.1 396*199*7*11 56.7 600*200*11*17 106 300*126*9 48.084 630*176*13 121.407 248*124*5*8 25.8 400*200*8*13 66 692*300*13*20 166 300*128*11 52.794 630*178*15 131.298 250*125*6*9 29.7 400*400*12*21 172 700*300*13*24 185 300*130*13 57.504 630*180*17 141.189 250*250*9*14 72.4 400*408*21*21 197 800*300*14*26 210 320*130*9.5 52.717 250*255*14*14 82.2 414*405*18*28 233 900*300*16*28 243 320*132*11.5 57.741
Material:S355JR,S355J0H,S355J2H,etc
Application:
1.Industrial structure of the steel structure bearing bracket.
2.Underground engineering steel pile and retaining structure.
3.Petrochemical and electric power and other industrial equipment structure
4.Large span steel bridge components
5.Ships, machinery manufacturing frame structure
6.The train, automobile, tractor beam bracket
7.Port of conveyor belt, high speed damper bracket
Material:S355JR,S355J0H,S355J2H,etc
Application:
1.Industrial structure of the steel structure bearing bracket.
2.Underground engineering steel pile and retaining structure.
3.Petrochemical and electric power and other industrial equipment structure
4.Large span steel bridge components
5.Ships, machinery manufacturing frame structure
6.The train, automobile, tractor beam bracket
7.Port of conveyor belt, high speed damper bracket
