High Quality Spiral Pipe (arc welded for submerged) (ZL-SP)
Guangzhou New Zhonglian Building Materials Co., Ltd.- Type：Welded
- Technique：ERW
- Material：Carbon Steel
- Surface Treatment：Black
- Usage：Pipeline Transport, Oil,Gas Drilling, Chemical Industry, Construction & Decoration
- Section Shape：Round
Base Info
- Model NO.：ZL-SP
- Standard Length：5.8m, 6.0m, 11.8m, 12.0m, or as Requried
- Application Range：Petroleum, Chemical,Gas,Water,Piles,Construction
- Transport Package：Standard Seaworthy Export Package
- Origin：Hebei
- Production Capacity：10000tons, Month
Description
Sign
SizeO.D.
(mm) Wall Thickness
(mm) Nominal weight
(kg/m) Test Pressure
(Mpa) L245 L290 L320 L360 L390 L415 L450 L285 L555 20 508 6.4 79.17 3.7 6.6 7.3 8.2 8.8 9.4 10.2 11.0 12.6 508 7.1 87.71 4.1 7.3 8.1 9.1 9.8 10.4 11.3 12.2 14.0 508 7.9 97.43 4.6 8.1 9.0 10.1 10.9 11.6 12.6 13.6 15.5 508 8.7 107.13 5.0 8.9 9.9 11.1 12.0 12.8 13.9 15.0 17.1 508 10.3 126.42 6.0 10.6 11.7 13.1 14.2 15.1 16.4 17.7 20.3 22 559 7.1 96.64 3.7 6.6 7.3 8.2 8.9 9.5 10.3 11.1 12.7 559 7.9 107.37 4.2 7.4 8.1 9.2 9.9 10.6 11.4 12.3 14.1 559 8.7 118.07 4.6 8.1 9.0 10.1 10.9 11.6 12.6 13.6 15.5 559 10.3 139.38 5.4 9.6 10.6 11.9 12.9 13.8 14.9 16.1 18.4 24 610 7.1 105.57 3.5 6.1 6.7 7.5 8.2 8.7 9.4 10.2 11.6 610 7.9 117.30 3.8 6.8 7.5 8.4 9.1 9.7 10.5 11.3 12.9 610 8.7 129.01 4.2 7.4 8.2 9.2 10.0 10.7 11.6 12.5 14.2 610 10.3 152.33 4.9 8.8 9.8 11.0 11.9 12.6 13.7 14.8 16.9 26 660 7.1 114.32 3.2 5.6 6.2 7.0 7.6 8.0 8.7 9.4 10.7 660 7.9 127.05 3.5 6.2 6.9 7.8 8.4 8.9 9.7 10.4 12.0 660 8.7 139.74 3.90 6.9 7.6 8.5 9.3 9.8 10.7 11.5 13.2 660 10.3 165.03 4.6 8.1 9.0 10.1 11.0 11.7 12.6 13.6 15.6 28 711 7.9 136.98 3.3 5.8 6.4 7.2 7.8 8.3 9.0 9.7 11.1 711 8.7 150.68 3.6 6.4 7.0 7.9 8.6 9.1 9.9 10.7 12.2 711 9.5 164.35 3.9 7.0 7.7 8.7 9.4 10.0 10.8 11.7 13.3 711 10.3 177.99 4.3 7.6 8.3 9.4 10.2 10.8 11.7 12.6 14.5 30 762 7.9 146.92 3.0 5.4 6.0 6.7 7.3 7.7 8.4 9.1 11.1
762 8.7 161.62 3.4 6.0 6.6 7.4 8.0 8.5 9.2 10.0 11.4
762 9.5 176.30 3.7 6.5 7.2 8.1 8.8 9.3 10.1 10.9 12.5
762 10.3 190.94 4.0 7.1 7.8 8.8 9.5 10.1 10.9 11.8 13.5 32 813 7.9 156.85 2.9 5.1 5.6 6.3 6.8 7.3 7.9 8.5 9.7
813 8.7 172.57 3.1 5.6 6.2 6.9 7.5 8.0 8.7 9.3 10.7
813 10.3 203.90 3.7 6.6 7.3 8.2 8.9 9.5 10.3 11.1 12.7
813 12.7 250.65 4.6 8.2 9.0 10.1 11.0 11.7 12.7 13.6 15.6 36 914 8.7 194.24 2.8 5.0 5.5 6.2 6.7 7.1 7.7 8.3 9.5
914 9.5 211.91 3.1 5.4 6.0 6.7 7.3 7.8 8.4 9.1 10.7
914 10.3 229.55 3.3 5.9 6.5 7.3 7.9 8.4 9.1 9.8 11.3
914 12.7 282.29 4.1 7.3 8.0 9.0 9.8 10.4 11.3 12.1 13.9 40 1016 9.5 235.81 2.7 4.9 5.4 6.1 6.6 7.0 7.6 8.2 9.3
1016 12.7 314.23 3.7 6.5 7.2 8.1 8.8 9.3 10.1 10.9 12.5
1016 14.3 353.26 4.1 7.3 8.1 9.1 9.9 10.5 11.4 12.3 14.1
1016 17.5 430.90 5.0 9.0 9.8 11.1 12.0 12.8 13.9 15.0 17.1 44 1118 9.5 259.70 2.5 4.4 4.9 5.5 6.0 6.3 6.9 7.4 8.5
1118 10.3 281.37 2.7 4.8 5.3 6.0 6.5 6.9 7.5 8.0 9.2
1118 12.7 346.18 3.3 5.9 6.5 7.4 8.0 8.5 9.2 9.9 11.3
1118 14.3 389.23 3.8 6.7 7.4 8.3 9.0 9.6 10.4 11.2 12.8
1118 20.6 557.47 5.3 9.6 10.5 11.9 12.8 13.7 14.9 16.0 18.3 48 1219 10.3 307.03 2.5 4.4 4.9 5.5 5.9 6.3 6.8 7.4 8.4
1219 12.7 377.81 3.1 5.4 6.0 6.8 7.3 7.8 8.4 9.1 10.4
1219 14.3 424.85 3.4 6.1 6.8 7.6 8.2 8.8 9.5 10.2 11.7
1219 20.6 608.75 4.8 8.8 9.6 10.9 11.7 12.6 13.6 14.7 16.8 52 1321 10.3 332.94 2.3 4.1 4.5 5.1 5.5 5.8 6.3 6.8 7.8
1321 12.7 409.76 2.8 5.0 5.5 6.2 6.7 7.2 7.8 8.4 9.6
1321 14.3 460.82 3.2 5.7 6.2 7.0 7.6 8.1 8.8 9.5 10.8
1321 22.2 711.30 4.9 8.8 9.6 10.9 11.7 12.5 13.6 14.6 16.7 56 1422 10.3 358.59
441.39
496.44 2.1 3.8 4.2 4.7 5.1 5.4 5.9 6.3 7.2
1422 12.7
2.6 4.7 5.1 5.8 6.3 6.7 7.2 7.8 8.9
1422 14.3
3.0 5.2 5.8 6.5 7.1 7.5 8.1 8.8 10.0
1422 22.2
4.5 8.1 8.9 10.1 10.8 11.6 12.6 13.6 15.5 60 1524 12.7 473.31 2.4 4.4 4.8 5.4 5.8 6.2 6.7 7.2 8.3
1524 15.9 591.32 3.0 5.4 6.0 6.7 7.2 7.8 8.4 9.1 10.4
1524 17.5 650.13 3.3 6.0 6.6 7.7 8.0 8.6 9.3 10.0 11.4
1524 22.2 822.16 4.2 7.6 8.3 9.4 10.1 10.7 11.7 12.7 14.5 64 1626 12.7 505.26 2.3 4.1 4.5 5.0 5.4 5.8 6.3 6.8 7.8
1626 15.9 603.31 2.8 5.1 5.6 6.3 6.8 7.3 7.9 8.5 9.7
1626 17.5 694.15 3.1 5.6 6.1 7.0 7.5 8.0 8.7 9.4 10.7
1626 22.2 878.0 3.9 7.1 7.8 8.0 9.5 10.2 11.0 11.9 13.6
Size
(mm)
(mm)
(kg/m)
(Mpa)
441.39
496.44
