Standard Size Hot Dipped Galvanized Steel C Channel
Guangzhou New Zhonglian Building Materials Co., Ltd.- Type：Cold Bending Inner Edge Channel
- Standard：GB, ASTM, JIS, AISI, DIN, BS
- Shape：C Channel
- Perforated：Perforated
- Length：5-12m
- Transport Package：for Exporting Packing or as Requirement
Base Info
- Model NO.：steel c channel
- Specification：AISI, ASTM, BS, DIN, GB, JIS
- Trademark：ZHONGLIAN
- Origin：China
- Production Capacity：50000pieces,Month
Description
Standard
ASTM,DIN,JIS,GB,EN,AS/NZS
Steel Grade
SS400,SS540,Q235B,Q345B,S235JR,G250,G350,G450
Thickness
0.7mm to 3.5mm
Length
any length
*Galvanized,Rex Oxide or Primer coating service Available
*Hole punching processing Available
Code
Size(HxBxCxT)
Weight(kg/m)
Code
Size(HxBxCxT)
Weight(kg/m)
1
80×40×20×2.5mm
3.925
21
180×60×20×2.5mm
6.673
2
80×40×20×3.0mm
4.71
22
180×60×20×3.0mm
8.007
3
100×50×20×2.5mm
4.71
23
180×70×20×2.5mm
7.065
4
100×50×20×3.0mm
5.652
24
180×70×20×3.0mm
8.478
5
120×50×20×2.5mm
5.103
25
200×50×20×2.5mm
6.673
6
120×50×20×3.0mm
6.123
26
200×50×20×3.0mm
8.007
7
120×60×20×2.5mm
5.495
27
200×60×20×2.5mm
7.065
8
120×60×20×3.0mm
6.594
28
200×60×20×3.0mm
8.478
9
120×70×20×2.5mm
5.888
29
200×70×20×2.5mm
7.458
10
120×70×20×3.0mm
7.065
30
200×70×20×3.0mm
8.949
11
140×50×20×2.5mm
5.495
31
220×60×20×2.5mm
7.4567
12
140×50×20×3.0mm
6.594
32
220×60×20×3.0mm
8.949
13
160×50×20×2.5mm
5.888
33
220×70×20×2.5mm
7.85
14
160×50×20×3.0mm
7.065
34
220×70×20×3.0mm
9.42
15
160×60×20×2.5mm
6.28
35
250×75×20×2.5mm
8.634
