Hot-Dipped Galvalume Steel Used for Machine Equipment
CHANGZHOU DINGANG METAL MATERIAL CO., LTD.- Type：Steel Coil
- Standard：ASTM, AISI, GB, JIS, DIN, BS
- Surface Treatment：Galvanized
- Technique：Cold Rolled
- Application：Ship Plate, Boiler Plate, Container Plate, Flange Plate
- Special Use：High-strength Steel Plate
Base Info
- Model NO.：GL
- Thickness：0.15-3.0mm
- Width：600-1250mm
- Form：Coil,Sheet
- Transport Package：strandard export packing
- Specification：JIS G 3302
- Trademark：Dingang
- Origin：china
- HS Code：72104900
- Production Capacity：3, 000, 000 Tons per year
Description
Basic Info.
Model NO. GL Thickness 0.15-3.0mm Width 600-1250mm Form Coil/Sheet Transport Package strandard export packing Specification JIS G 3302 Trademark Dingang Origin china HS Code 72104900 Production Capacity 3, 000, 000 Tons per yearProduct Description
Hot-dipped Galvalume Steel sheet1)Commodity: Hot-dipped Galvalume Steel sheet
2)Standard: JIS G3302 SGCC, commercial quality of the Steel base.
3)Thickness range of the Hot-dipped Galvalume Steel sheet: 0.18mm to 1.5mm
4)Tolerance of thickness of the Hot-dipped Galvalume Steel sheet: +/-0.03mm
5)Width range: 700mm to 1250mm
6)Tolerance of width: +/-3.00mm (aiming to +/-2.00mm)
7)weight of Hot-dipped Galvalume Steel sheet: According to Clients' requests.
8)Coil ID: 508 mm
9)Packing of Galvanized Steel roll: Seaworthy, in container
10)Note of the GI: Special width can be requested, the small order can be negotiated.
| Standard | AISI, ASTM, BS, DIN, GB, JIS, etc |
| Grade | SGCC, DX51D, DX53D, DX54D, etc |
| Thickness | 0.15-3.0mm |
| Width | less than 1500mm |
| Inner Diameter | 508/610mm |
| Zinc Coating | 60g/m 2 -180g/m 2 |
| Coil Weight | 3-8 Tons |
| Technology | hot dip galvanized and electro galvanized |
| Spangle State | regular spangle, small spangle, big spangle, non-spangle |
