1.2738 718H Hot Rolled Steel Bar of Plastic Mould Steel
Guangzhou Changfeng Steel Co., Ltd.- Type：Alloy Steel Bar
- Standard：AISI, ASTM, GB, JIS, DIN, BS
- Technique：Hot Rolled
- Application：Tool Steel Bar, Die Steel Bar
- Surface Treatment：black
- Alloy：Alloy
Base Info
- Model NO.：1.2738, P20+Ni, 718H
- Special Use：Mold Steel
- Shape：Round Bar or Flat Steel
- Composition：Ferrous Steel Scrap
- Grade：1.2738, P20+Ni, 3cr2nimnmo
- Heat Treatment：Annealed , Q+T
- Test：Ut 100% , SGS
- Delivery Quantiity：Include MOQ
- Payment：T,T L,C at Sight
- Transport Package：Export Standard Packing or Customers′demand
- Specification：diameter 10-350mm
- Trademark：CF STEEL
- Origin：China
- HS Code：72254
- Production Capacity：1000 Mt,Per Month
Description
Elastic ModulusHB Mpa KSI Mpa KSI % Z% GPA KSI 300 826 120 993 145 17 59 205 29745
7, Hardness: 33-37HRC
8, Packing: Standard Export Packing or As per request
9, Delivery date:
Abundant stock, 7-15 days.
Customized products, 30-50 days.
10, The process flow
1) Hot rolled or forged condition, Pre-harden &tempering , black surface
2) Hardness: 30~36HRC
3) Hot rolled technology:EAF+LF+VD
Forged technology: EAF+LF+VD+ESR+Forging +Q T + Machined surface
11, Contact details: You may contact to get further information!
1.2738 P20 Ni round bar, flat bar, plate and block.As an alloy tool steel grade 1.2738 P20 Ni is commonly supplied in the hardened and tempered condition with a supply high hardness.This steel gives an excellent polished finish and is one of the most widely accepted specifications for machine cut plastic moulds and zinc die casting dies. This grade gives excellent wear resistance but if maximum surface hardness is required for compression moulding plastic dies or similar tools, the steel can be case hardened or nitrided.
