Hot Rolled Carbon Steel C Channel U Channel Beam
Guangzhou New Zhonglian Building Materials Co., Ltd.- Type：Cold Bending Equal Channel
- Standard：GB, ASTM, AISI, DIN, BS
- Shape：U Channel
- Perforated：Not Perforated
- Length：5-12m
- Finish：Black, Galvanized, Painted
Base Info
- Model NO.：ZL-UC
- Edge Type：Equal Edge
- Transport Package：Standard Export Seaworthy Packing
- Specification：6meter , 9meter , 12 meter
- Origin：Hebei, China
- HS Code：721661
- Production Capacity：5000 Mt,Month
Description
Size
(mm)Theoretical
weight
(kg/m) Size
(mm) Theoretical
weight
(kg/m) 5 50*37*4.5 5.438 22b 220*79*9 28.453 6.3 63*40*4.8 6.634 25a 250*78*7 27.41 6.5 65*40*4.8 6.709 25b 250*80*9 31.335 8 80*43*5 8.045 25c 250*82*11 35.26 10 100*48*5.3 10.007 28a 280*82*7.5 31.427 12 120*53*5.5 12.059 28b 280*84*9.5 35.823 12.6 126*53*5.5 12.318 28c 280*86*11.5 40.219 14a 140*58*6 14.535 30a 300*85*7.5 34.463 14b 140*60*8 16.733 30b 300*87*9.5 39.173 16a 160*63*6.5 17.24 30c 300*89*11.5 43.883 16b 160*65*8.5 19.752 36a 360*96*9 47.814 18a 180*68*7 20.174 36b 360*98*11 53.466 18b 180*70*9 23 36c 360*100*13 59.118 20a 200*73*7 22.64 40a 400*100*10.5 58.928 20b 200*75*9 25.777 40b 400*102*12.5 65.204 22a 220*77*7 24.999 40c 400*104*14.5 71.488
(mm)
weight
(kg/m)
(mm)
weight
(kg/m)
