• Model NO.：KM-307
• Special Use：Cutting Tools, Measuring Tools, Cutters in Common Steel, High-strength Steel Plate, Wear Resistant Steel
• Stock：Not Stock
• Width：10mm~3500mm
• Length：2m,3m,6m,8m,12m, or as Required.
• Surface：Varnished,PE Coated,Galvanized.
• MOQ：1000kgs
• Price Term：Ex-Work,Fob,CIF,CFR,etc.
• Delivery Time：Prompt Delivery, or as Order′s Quantity.
• Transport Package：Standard Export Seaworthy
• Specification：Thickness: 0.3mm~500mm
• Trademark：KINGMETAL
• Origin：China
• Production Capacity：300 Ton,Month

Basic Info.

Model NO. KM-307 Special Use Cutting Tools, Measuring Tools, Cutters in Common Steel, High-strength Steel Plate, Wear Resistant Steel Stock Not Stock Width 10mm~3500mm Length 2m,3m,6m,8m,12m, or as Required. Surface Varnished,PE Coated,Galvanized. MOQ 1000kgs Price Term Ex-Work,Fob,CIF,CFR,etc. Delivery Time Prompt Delivery, or as Order′s Quantity. Transport Package Standard Export Seaworthy Specification Thickness: 0.3mm~500mm Trademark KINGMETAL Origin China Production Capacity 300 Ton//Month

Product Description

ASTM A204 EN10028 16Mo3 Alloy Steel plates

16mo3 Plate Specification

Grade	ASTM A204 16MO3, SA 204 M Gr (A, B, C) Hot Rolled Plate
ASTM A204 16Mo3 Plate Specifications	ASTM A204 / ASME SA204, SA 204 M gr (A, B, C)
16Mo3 / SA 204 Steel Plate Standard	ASTM, ASME, and API
ASTM A204 16Mo3 Alloy Steel plates Thickness	8-700mm
16mo3 Plate Width	1500- 4020mm
SA 204 Gr B 16mo3 Plate Length	3000-27000mm
16mo3 Plate Weight	Max 35 tons per plate
ASTM A204 Gr.B 16Mo3 Plates Delivery Condition	AR, TMCP, N, T, A, N&T, Q&T as required, as well as Z15, Z25, Z35.
16Mo3 Cr-Mo steel plate Packing	Loose, Bundle and Bare, According to Customer requirement
16mo3 Plate Application	Petroleum, power plants, chemical engineering, boilers and other industries for the production of the reactor, heat exchangers, boiler, separators, tank, gas tank, liquefied petroleum gas cylinders, Hydropower high-pressure pipes, turbine spiral case equipment and components.
16Mo3 clad steel plate Specialize	Shim Sheet, Perforated Sheet, B. Q. Profile.
16Mo3 Steel Plates Form	Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
ASTM A204 16Mo3 Alloy Steel plates Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
ASME SA 204 16Mo3 Plates Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

16mo3 Plate Properties

SA204 Carbon-Molybdenum Alloy Steel Pressure Vessel Plates Tensile Requirements

	Grade A	Grade B	Grade C
ksi	[MPa]	ksi	[MPa]	ksi	[MPa]
Tensile strength	65-85	[450-585]	70-90	[485-620]	75-95	[515-655]
Yield strength, min.A	37	[255]	40	[275]	43	[295]
Elongation in 8 in. [200 mm], min, %	19B	17B	16B
Elongation in 2 in. [50 mm], min, %	23B	21B	20B

• Determined by either the 0.2% offset method or the 0.5% extension-under-load-method.
• See Specification A 20/A 20M.

16MO3 STEEL PLATE MECHANICAL PROPERTIES:

	16Mo3
Tensile Strength (MPa)	440 - 590
Yield Strength (MPa)	220 - 275
Elongation in 100 - 150mm (%)	19
Elongation in 16mm (%)	24
Max Thickness (mm)	250



ASTM A204 GR A / B / C steel Plates Chemical Composition % :

Main chemical composition in ASTM A204 / SA204 GR A / B / C Steel Plate

Grades	C max	Mn max	S max	P max	Si	Cr	Cu	Mo
SA204 gr A	0.18	0.90	0.035	0.035	0.15-0.40	-	-	-
SA204 gr B	0.20	0.90	0.035	0.035	0.15-0.40	-	-	-
SA204 g rC	0.23	0.90	0.035	0.035	0.15-0.40	-	-	-



ASTM A204 GR A / B / C steel Plates Mechanical Properties

ASTM A204 / SA204 gr A / B / C steel plate grade is a kind of steel which with Cr., Mo., Cr-Mo and mainly used for pressure vessels.

Grade	Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation in 100-150 mm(%)	Elongation in 16 mm(%)	Max Thickness (mm)
A204	440-590	220-275	19	24	250



Grade	Maximum Thickness, in. [mm]
SA204 A	6 [150]
SA204 B	6 [150]
SA204 C	4 [100]

16mo3 Equivalent ASME Material

16mo3 material equivalent

STANDARD	EN	ASTM / ASME	DIN	WERKSTOFF NR.	JIS	BS
Alloy Steel 16MO3	10028-2	ASTM A204 Gr.B	17155	2.5415	JIS G3115	1503-243B



ASTM A204 GR A / B / C

AFNOR 36206

15CD 2.05

Technical conditions

1) Ultrasonic tested as per SA 578 or any other as per requirement
2) MTC acc to EN 10204 3.1 / 3.2
3) Charpy Impact tested at -20 / - 46 DegC.
4) Furnace Normalised
5) 16MO3 En 10028 BQ Plates with IBR form IV
