Epoxy Coated Dowel Bar
Laiwu Xincheng Metal Co., Ltd.- Type:Dowel Bar
- Standard:AISI, ASTM, GB, JIS, BS
- Technique:Epoxy Coated
- Products:Epoxy Coated Dowel Bar
- Techniques:Epoxy Coated
- Length:100-1000mm ( as Required )
Base Info
- Model NO.:Epoxy coated dowel bar
- Dowel Bar Standard:ASTM A1078,A1078m
- Coating Standard:BS 7295, ISO 14654 ASTM A775,A775m
- Steel Standard:BS 4449 ASTM A615,A615m
- Steel Material:BS: Grade 250 ASTM: Gr40 Gr60
- Length Cutting:Saw Cut
- Surface and Cut Surface:Smooth
- Commodity:Pre Cut Dowel Bar - Epoxy Coated
- MOQ:25tons
- Delivery Time:30 Days as Per The Production Plan
- Payment Term:Tt LC
- Advantages:One-Stop Solution for Dowel Bar
- Coating:Fusion Bonded Epoxy
- Transport Package:by Wooden Box
- Specification:16-60mm
- Origin:China
- Production Capacity:2000tons,Month
Description
Basic Info.
Model NO. Epoxy coated dowel bar Dowel Bar Standard ASTM A1078/A1078m Coating Standard BS 7295, ISO 14654 ASTM A775/A775m Steel Standard BS 4449 ASTM A615/A615m Steel Material BS: Grade 250 ASTM: Gr40Gr60 Length Cutting Saw Cut Surface and Cut Surface Smooth Commodity Pre Cut Dowel Bar - Epoxy Coated MOQ 25tons Delivery Time 30 Days as Per The Production Plan Payment Term Tt LC Advantages One-Stop Solution for Dowel Bar Coating Fusion Bonded Epoxy Transport Package by Wooden Box Specification 16-60mm Origin China Production Capacity 2000tons/MonthProduct Description
Epoxy coated dowel barPre Cut Dowel Bar - Epoxy Coated
1.Why choose Epoxy coated Dowel BarSteel corrosion is an important problem affffecting their structural durability. Especially in coastal erosion environment, concrete structure damage caused by chloride ion corrosion on steel bars has brought huge losses to engineerings.
2.Advantage of Epoxy coated dowel bar:
Different from traditional black steel bar, fusion bonded epoxy coated dowel bar features its corrosion-resistent epoxy coating, by which the inner bar can be protected from the damage of deicing salts or saltwater.
3.Features of Epocy Coated Dowel Bar
Dowel bars provide a mechanical connection between slabs without restricting horizontal joint movement. Dowels are saw cut to customized length.
4.Uses
Inserted at mid-slab depth to help transfer load but allow adjacent slabs to expand and contract independent of one another
5.Details for our Epoxy Dowel Bar
Dowel bar standard | ASTM A1078/A1078M |
Coating standard | BS 7295, ISO 14654 ASTM A775/A775M |
Steel standard | BS 4449 ASTM A615/A615M |
Steel material | BS: Grade 250 ASTM: Gr40Gr60 |
Diameter | 16mm - 60mm |
Length | 100mm - 1000mm( Tailored length) |
6.Weight of some sizes of Dowel Bar
Diameter (mm) | 16 | 20 | 22 | 25 | 30 | 36 | 38 | 40 |
Weight (kg/m) | 1.58 | 2.47 | 2.98 | 3.85 | 5.55 | 7.99 | 8.95 | 9.87 |
We purse honest cooperation with clients all over the world, no matter whether you place order with us, you will enjoy down-to-earth service from us. If you are interested in some of our products, please contact me or send me an inquiry directly for details. We are looking forward to establishing long-lasting business relations with you in the future. Welcome your inquiry us at any time.
For more information, please feel free to contact with me directly.
