• Model NO.：WAN335
• Length：5.8-11.8
• Size：1,2"-8"
• Name：Steam Boiler Pipe
• Product Material：15NiCuMoNb5,Wb36,1.6368
• Keyword：Alloy C276, Hastelloy C-276
• Tag：Alloy Pipes
• MOQ：200kg
• Transport Package：Bundles with Steel Strips and Wooden Frame
• Specification：1,8"-2"
• Trademark：KINGMETAL
• Origin：China
• HS Code：73060000
• Production Capacity：100000tons,Month

Basic Info.

Model NO. WAN335 Length 5.8-11.8 Size 1/2"-8" Name Steam Boiler Pipe Product Material 15NiCuMoNb5/Wb36/1.6368 Keyword Alloy C276, Hastelloy C-276 Tag Alloy Pipes MOQ 200kg Transport Package Bundles with Steel Strips and Wooden Frame Specification 1/8"-2" Trademark KINGMETAL Origin China HS Code 73060000 Production Capacity 100000tons/Month

Product Description

1.ASTM B 622  UNS  N10276  steel pipe
Other common names:  Alloy C276, Hastelloy C, Inconel® C-276
Outer Diameter: 10mm-273.1mm
Wall Thickness: 1mm to 14mm

2 . Other material besides Uns N10276 seamless steel pipe we can do :
 Incoloy800/800H/800HT(UNS N08800/N08810/N08811),
Incoloy825(UNS N08825/2.4858),Inconel 600 / 601 / inconel 625(UNS N06600 / N06601 / N06625),Inconel 725 (N07725)
Incoloy901/925/926(N09901/N08925/N08926),GH3030(80Ni20Cr),Monel400(N04400/2.4360),
Nickel200(N02200/2.4060),Hastelloy C-276(N10276/2.4819)
Alloy C276 Pipes

3 .Chemipetro supplies C276 steel pipes in the following Product Forms:

Seamless pipe to ASTM B622 and ASME SB622
Welded pipe to ASTM B619 and ASME SB619
Flanges to ASTM B564 and ASME SB564
Fittings to ASTM B366 and ASME SB366
Bar to ASTM B574 and ASME SB574
Plate to ASTM B575 and ASME SB575

4 .What are the characteristics of Hastelloy C276 steel pipe?

Excellent corrosion resistance in reducing environments
Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
High nickel and molybdenum contents providing good corrosion resistance in reducing environments
Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in
heat-affected zones of welded joints
Resistance to localized corrosion such as pitting and stress-corrosion cracking
One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide

                                    C276 Nickel Alloy Pipe Chemical Composition, %

Ni	Mo	Cr	Fe	W	Co	Mn	C
Remainder	15.0-17.0	14.5-16.5	4.0-7.0	3.0-4.5	2.5 max	1.0 max	.01 max
V	P	S	Si
.35 max	.04 max
