Hot Rolled A588 A242 SPA-H Corten a Steel Plate

Shandong Heng Steel Group Co., Ltd.
  • After-sales Service:Yes
  • Warranty:Yes
  • Type:Steel Plate
  • Standard:ASTM, AISI, JIS, DIN, BS
  • Certification:ISO, RoHS, IBR
  • Surface Treatment:Hot-Rolled,Controlled;Rolling,Normalizing;...

Base Info

  • Model NO.:Hot Rolled A588 A242 SPA-H Corten A Steel Plate
  • Technique:Hot Rolled
  • Application:Corten Steel Plate
  • Special Use:Corten Steel Plate
  • Stock:Stock
  • Name:Hot Rolled A588 A242 SPA-H Corten a Steel Plate
  • Thickness:0.5-300mm
  • Width:1000-3000mm
  • Length:100-11800mm
  • Material:A588gr.a,Gr.B, A242,09cupcrni-a,SPA-H...
  • Surface:Clean, Finishing,Blasting and Painting...
  • Delivery Status:Hot-Rolled;Controlledrolling;Normalizing,
  • Test:BV,SGS---Mtc
  • Package:Standard Export Package
  • MOQ:5 Tons
  • HS Number:72254099
  • Original:China
  • Delivery Time:About 10-15 Workdays
  • Use:Buildings,Bridges,Ships etc.
  • Sample:Free
  • Transport Package:Standard Export Package
  • Specification:0.5-300mm*1000-3000mm
  • Trademark:Hengze
  • Origin:China
  • HS Code:72254099
  • Production Capacity:2500 Ton , Month

Description

Overview
                        Corten Steel Plate Specification




Standard

GradeASTM: Corten A; Corten B; A588Gr.A/Gr.B/Gr.C/ Gr.K; A242; A606 Type 4; A709 Gr 50W;
 EN10025: S235J0W; S235J2W; S355J0W; S355J2W; S355K2W; S355J0WP; S355J2WP; S355J2G1W; S355J2G2W; S355K2G1W, S355K2G2W;
 JIS G3114: SMA400AW; SMA400BW; SMA400CW; SMA490AW; SMA490BW; SMA490CW; SMA570W; SMA570P;
JIS G3125: SPA-H; SPA-C;
GB/T 4171: Q235NH; Q265GNH; Q310GNH; Q295NH; Q295GNH; Q355NH; Q355GNH; Q415NH; Q460NH; 1500NH; Q550NH;
TB/T 1979: 09CuPCrNi-A; 09CuCrNi-B; 05CuPCrNi;
Q/BQB 340: B460NQR; B490NQR; B480GNQR; B600GNQR;ThicknessCold Rolled 0.5-2mm Hot Rolled 2-300mm (2-100mm usually used)Width 1000-3000mm (1000-2200mm usually used)Length 1000-12000mm or as your requestSurfaceClean, finishing,blasting and painting according to customer requirementDelivery
StatesHot-rolled, Controlled rolling, Normalizing, Annealing, Tempering,
 Quenching, N+T, Q+T,and other delivery states are available as requiredCertificate API,ISO,SGS,BV,CE etcQualityMTC will be provided with goods, third part inspection is acceptable, for example:BV,SGS. PackageStandard export seaworthy package,suit for all kinds of transport,or as required.Container
Size
 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)Trade termEx-Work,FOB,CNF,CFR,CIF,etcApplicationWidely used in a variety of architectural and engineering structures,such as
1.) metal constructions such as buildings,bridges,ships;
2.) transmission tower, reaction tower;
3.) lifting transportation machinery;
4.) industrial furnace;boilers
5.) container frame, warehouse goods shelves, etc
       Corten Steel Plate Chemical Composition and Mechanical PropertiesGradeCSiMnPSCrNiCuCORTEN A≤0.120.25-0.750.20-0.500.07-0.15≤0.0300.50-1.25≤0.650.25-0.55CORTEN B≤0.160.30-0.500.80-1.250.030≤0.0300.40-0.650.400.25-0.40Product Description
