ASME B16.20 Stainless Steel 316 Graphite Spiral Wound Gasket

HEBEI HONGCHENG PIPE FITTINGS CO., LIMITED
  • Type：Gasket
  • Standard：ASTM, AISI, GB, JIS, DIN, EN
  • Certification：ISO, RoHS, IBR, AISI, ASTM, GB, EN, DIN, JIS
  • Shape：Round
  • Technique：Cold Rolled
  • Surface Treatment：Polished

Base Info

  • Model NO.：316 Graphite Spiral Wound Gasket
  • Mtc：Mtc En10204 3.1 Will Be Provided to All Goods.
  • Transport Package：Sea Worthy
  • Specification：customizable
  • Trademark：C&N
  • Origin：China
  • Production Capacity：100000pics,Year

Description

FillingSteel bandInner ringOuter ringAsbestos wrappingSUS 304Carbon steelCarbon steelGraphite wrappingSUS 316SUS 304SUS 304Teflon wrappingSUS 316LSUS 316SUS 316  SUS 316LSUS 316LFillingTemperature(ºC)Max operating pressure(kg/cm2)Asbestos wrapping-200~550250Graphite wrapping-150~450100Teflon wrapping240~260100Flange typeSpiral wound gasket formFlat face flange(F.F)Wrapping pad with outer ring onlyWrapping pad with inner and outer ringsRaised face flange(R.F) Wrapping pad with outer ring onlyWrapping pad with inner and outer ringsMale and female flange(M & F)Basic wrapping padWrapping pad with inner ring onlyTongue and groove flange(T & F)Basic wrapping padWrapping pad with inner ring onlyFlat and groove flange(F & G)Basic wrapping padWrapping pad with inner ring onlyWrapping pad coefficientm=2.5-4Wrapping pad service pressure≤25MPaWrapping pad service temperature-196ºC-700ºC(Oxidizing medium no higher than 600ºC)Wrapping pad minimum pretension specific pressurey=68MPa
