Heat-Resisting 2.4603/Hastelloy G-30 Cold Rolled Steel Plate
Shanghai Bozhong Metal Group Co., Ltd.- Type：Stainless Steel Sheets
- Standard：ASTM, AISI, GB, JIS, DIN
- Grade：300 Series
- Certification：ISO, RoHS, IBR
- Shape：Round
- Technique：Hot Rolled
Base Info
- Model NO.：2.4603
- Surface Treatment：Bright
- Transport Package：Fumigated Wooden Box
- Specification：0.3mm*1219mm*6000mm
- Trademark：Bao steel
- Origin：China
- HS Code：7211190000
- Production Capacity：5000mt,Mt
Description
Basic Info.
Model NO. 2.4603 Surface Treatment Bright Transport Package Fumigated Wooden Box Specification 0.3mm*1219mm*6000mm Trademark Bao steel Origin China HS Code 7211190000 Production Capacity 5000mt/MtProduct Description
Heat-Resisting 2.4603/Hastelloy G-30 cold rolled steel Plate1.Product Description
| Product Name | Heat-Resisting 2.4603/Hastelloy G-30 cold rolled steel Plate |
| Type | Hot Rolled, Cold Drawn, Oil Tempered, Heat Treatment |
| Standard | GB, AISI, ASTM, DIN, EN, SUS, UNS |
| Thickness | 0.04-10mm |
| Width | 5-2000mm |
| Price Item | EXW, FOB, CIF, CFR, DDP etc |
| Material | Inconel: Inconel100 Inconel 600 Inconel 601 Inconel602CA Inconel 617 Inconel 625LCF Inconel 686 Inconel 690 Inconel 718 Inconel 725 Inconel X-750 Hastelloy: Hastelloy B Hastelloy B-2 Hastelloy B-3 Hastelloy C Hastelloy C-22 Hastelloy C -4 Hastelloy C-276 Hastelloy C-2000 Hastelloy G Hastelloy G-30 Hastelloy G-35 Monel: Monel 400 Monel 401 Monel 404 Monel R405 Monel K-500 Nickel: Nickel 200 Nickel 201 Nickel 205 Nimonic: Nimonic 75 Nimonic 80A Nimonic 90 Nimonic 105 Nimonic 115 Nimonic 901 Udimet: Udimet 188 Udimet 720 Udimet R41 Udimet 300 Haynes: Haynes 230 Haynes 556 Haynes 188 Incoloy: Incoloy 800 Incoloy 800H Incoloy 800HT Incoloy 825 Incoloy 925 Incoloy 926 GH: GH2132 GH3030 GH3039 GH3128 GH4180 GH3044 Alloy : Alloy 20/28/31; 200 series: 201,202,202Cu,204Cu, 300 series: 301,303/Cu,304/L/H,304Cu,305,309/S,310/S,316/L/H/Ti,321/H,347/H,330, 400 series: 409/L,410,416/F,420/F,430,431,440C,441,444,446, 600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A/B/C/D, S32760,2304,LDX2101,LDX2404,LDX4404,904L; Others: 254SMo,253Ma,F15,Invar36,1J22,N4,N6 etc. |
| Delivery time | 5-30 days after order confirmed, according to customer's quantity. |
Stainless steel plate/Stainless steel sheet
Grade: Stainless Steel 200 series: AISI 201, AISI 202
Stainless Steel 300 series: AISI 304, AISI 304L, AISI 316L, AISI 321, AISI 309S,AISI 310S
Stainless Steel 400 series: AISI 430, AISI 409L, AISI 443, AISI 439, AISI 441,AISI 444, AISI 436L
Chemical composition
| Grade | C | Si | Mn | P | S | Ni | Cr |
| AISI 201 | <=0.15 | <=1.00 | 5.5-7.5 | <=0.060 | <=0.03 | <=3.50-5.50 | <=16.00-18.00 |
| AISI 202 | <=0.15 | <=1.00 | 7.5-10.0 | <=0.060 | <=0.03 | <=4.0-6.0 | <=17.00-19.00 |
| AISI 304 | <=0.07 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=8.00-10.5 | <=18.00-20.00 |
| AISI 316L | <=0.03 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=12.00-15.00 | <=16.00-18.00 |
| AISI 309S | <=0.08 | <=1.00 | <=2.0 | <=0.045 | <=0.03 | <=12.00-15.00 | <=22.00-24.00 |
| AISI 310S | <=0.08 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=19.00-22.00 | <=24.00-26.00 |
| AISI 321 | <=0.08 | <=1.00 | <=2.00 | <=0.045 | <=0.03 | <=9.00-13.00 | <=17.00-19.00 |
| AISI 409L | <=0.08 | <=1.00 | <=1.00 | <=0.045 | <=0.03 | <=0.50 | <=10.50-17.50 |
| AISI 430 | <=0.12 | <=0.75 | <=1.00 | <=0.040 | <=0.03 | <=0.60 | <=16.00-18.00 |
| AISI 436L | <=0.025 | <=16.00-19.00 | |||||
| AISI 439 | <=0.03 | <=1.00 | <=1.00 | <=0.040 | <=0.03 | <=0.50 | <=17.00-19.00 |
| AISI 441 | <=0.015 | <=1.00 | <=1.00 | <=0.040 | <=0.03 | <=0.30 | <=17.50-19.00 |
| AISI 444 | <=0.025 | <=1.00 | <=1.00 | <=0.040 | <=0.03 | <=1.00 | <=17.50-19.50 |
Mechanical property
| YIELD STRENGTH | TENSILE STRENGTH | EXTENSION | HARDNESS | |||
| N/mm2 | N/mm2 | % | HRB | HV | HB | |
| AISI 201 | >=270 | >=520 | >=40 | <=100 | <=253 | <=241 |
| AISI 202 | >=245 | >=590 | >=40 | <=95 | <=218 | <=207 |
| AISI 304 | >=205 | >=520 | >=40 | <=90 | <=200 | <=187 |
| AISI 316L | >=175 | >=480 | >=40 | <=90 | <=200 | <=187 |
| AISI 309S | >=205 | >=520 | >=40 | <=90 | <=200 | <=187 |
| AISI 310S | >= 205 | >=520 | >=40 | <=90 | <=200 | <=187 |
| AISI 321 | >=205 | >=520 | >=40 | <=90 | <=200 | <=187 |
| AISI 409L | >=175 | >=360 | >=25 | <=80 | <=175 | <=162 |
| AISI 430 | >=205 | >=450 | >=22 | <=88 | <=200 | <=183 |
| AISI 439 | >=245 | >=410 | >=20 | <=96 | <=230 | <=217 |
| AISI 441 | >=302 | >=495 | >=35 | <=96 | <=170 | <=217 |
| AISI 444 | >=245 | >=410 | >=20 | <=96 | <=230 | <=217 |
Packaging & Shipping
| PackagingDetails: | Products are well packed and clear labeled according to the regulations and customer's requests. |
| Delivery Detail: | 7-15days after receiving deposit |
Our Services
Pre-sale Service
1. Sample can be offered with sample charge and courier fee by buyer's side.
2. We have full stock,and can deliver within short time.Many styles for your choices.
3. OEM and ODM order are accepted, Any kind of logo printing or design are available.
4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.
5. All of our products are produce by our professional workman and we have our high-work-effect foreign trade
team, you can totally believe our service.
6. We have 8 year experience of design, manufacture and sell lingerie, we cherish every order from our honor.
After you choose
1. We will count cheapest shipping cost and make invoice to you at once.
2. Check quality again, then send out to you at 1-2 working day after your payment.
3. Email you the tracking no, and help to chase the parcels until it arrive you.
After-sale choose
1. We are very glad that customer give us some suggestion for price and products.
2. If any question,please contact with us freely by E-mail or Telephone.
FAQ
1. If we travel to China to checking your facility, are you welcome?
Of course, why not ? we will provide the whole accompany from you landing in China. Only Give us a call before your arrive. We will pick up you from the airport, living in our company's hotel, and driving by car take you visiting our company. Warm Welcome!
2. How many sales person in your team?
present 8 sales, but more hands help in work, total team is 20+ workers. So do not worry, not the one person company.
3. How Many Years of your company working in this industry?
We are 20+ years, from last century. Expanding the market, and cultivate our techniques, two ways all in work together.
4. Could you show me some photos of your producing working?
here, following is our working plant, all is same when you come to China to audit.
