SUS 304 SUS316L Stainless Steel Angle Bar #3 #4 316 Steel Angel Bar Industry
Wuxi City Ge Ming Sheng Steel Trading Co., Ltd- Type：Stainless Steel Angles
- Standard：ASTM
- Grade：300 Series
- Shape：Angle
- Technique：Hot Rolled
- Surface Treatment：Bright
Base Info
- Model NO.：SUS304 SUS316L
- Transport Package：Wooden Box
- Specification：30*30-100*100
- Trademark：TISCO BAO STEEL
- HS Code：7219340000
Description
Basic Info.
Model NO. SUS304 SUS316L Transport Package Wooden Box Specification 30*30-100*100 Trademark TISCO BAO STEEL HS Code 7219340000Product Description
304 316L 310S Stainless Steel Angle Bar Equal/Unequal304 stainless steel angel bar
Equal angel steel bar and unequal angle steel bar
Stainless steel angel bar:long strips of steel perpendicular to each other in the form of angles
Stainless steel equal angel bar/stainless steel unequal angel bar
Product description
| Product Name | Stainless steel angel bar |
| Material | 304 316 310s 2205 |
| Price term | FOB/CIF/CFR/EXW |
| Standard | AISI ASTM JIS |
| Packing | According to the requirements |
| Certifactions | ISO/SGS/BV |
| Delivery time | 5-10 days,Based on stock and order quantity |
| Payment term | 30% deposit by T/T,70% before shipment |
Application
Angle steel can be made up of various bearing members according to the different needs of the
structure,and can also be used as a joint between members
Widely used In various construction structures and engineering structures, such as building
beams, Bridges,transmission towers, hoisting and transportation machinery, ships, industrial
furnaces, reaction towers, container racks, cable trench supports, power distribution pipes, bus
support installation,and warehouse shelves
Size
| Specification (side length * thickness)mm | Quality(kg/m) | Specification (side length * thickness)mm | Quality(kg/m) |
| 20*3 | 0.89 | 80*5 | 6.21 |
| 20*4 | 1.15 | 80*6 | 7.38 |
| 25*3 | 1.12 | 80*7 | 8.53 |
| 25*4 | 1.46 | 80*8 | 9.66 |
| 30*3 | 1.37 | 80*10 | 11.87 |
| 30*4 | 1.79 | 90*6 | 8.35 |
| 36*3 | 1.66 | 90*7 | 9.66 |
| 36*4 | 2.16 | 90*8 | 10.95 |
| 36*5 | 2.65 | 90*10 | 13.48 |
| 40*3 | 1.85 | 90*12 | 15.94 |
| 40*4 | 2.42 | 100*6 | 9.37 |
| 40*5 | 2.98 | 100*7 | 10.83 |
| 45*3 | 2.09 | 100*8 | 12.28 |
| 45*4 | 2.74 | 100*10 | 15.12 |
| 45*5 | 3.37 | 100*12 | 17.9 |
| 45*6 | 3.99 | 100*14 | 20.61 |
| 50*3 | 2.33 | 100*16 | 23.26 |
| 50*4 | 3.06 | 110*7 | 11.93 |
| 50*5 | 3.77 | 110*8 | 13.53 |
| 50*6 | 4.46 | 110*10 | 16.69 |
| 56*3 | 2.62 | 110*12 | 19.78 |
| 56*4 | 3.45 | 110*14 | 22.81 |
| 56*5 | 4.25 | 125*8 | 15.5 |
| 56*8 | 6.57 | 125*10 | 19.13 |
| 63*4 | 3.91 | 125*12 | 22.7 |
| 63*5 | 4.82 | 125*14 | 26.19 |
| 63*6 | 5.72 | 140*10 | 21.49 |
| 63*8 | 7.47 | 140*12 | 25.52 |
| 63*10 | 9.15 | 140*14 | 29.49 |
| 70*4 | 4.37 | 140*16 | 33.39 |
| 70*5 | 5.4 | 160*10 | 24.73 |
| 70*6 | 6.41 | 160*12 | 29.39 |
| 70*7 | 7.4 | 160*14 | 33.99 |
| 70*8 | 8.37 | 160*16 | 38.52 |
| 75*5 | 5.82 | 180*12 | 33.16 |
| 75*6 | 6.91 | 180*14 | 38.38 |
| 75*7 | 7.98 | 180*16 | 43.54 |
| 75*8 | 9.03 | 180*18 | 48.63 |
| 75*10 | 11.09 | 200*14 | 42.89 |
| 200*16 | 48.68 | ||
| 200*18 | 54.4 | ||
| 200*20 | 60.06 | ||
| 200*24 | 71.17 |
