Super Duplex Stainless Steel Pipe 2205 2507 Uns S32205 S331803 S332750 S32760
Dongtai Zhonghai Super Alloy Co., Ltd.- Type：Flat
- Standard：AISI, ASTM, DIN, JIS, GB, BS
- Technique：Cold Drawn
- Surface Treatment：Polished
- Special Use：High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Cold Heading Steel, Free Cutting Steel, Mold Steel
- Transport Package：Wooden Case
Base Info
- Model NO.：duplex
- Specification：S31803, 2205, Uns S32750, 904L
- Trademark：C&N
- Origin：C&N
- HS Code：7304419000
- Production Capacity：600ton,Year
Description
| Inspection & Test |
| 1.100% PMI, Spectro Chemical Analysis Test for Raw Material |
| 2.100% Dimension & Visual Examination |
| 3. Mechanical Properties Test Include Tension Test Flattening Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test |
| 4.100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test (ET or UT) |
| 5.Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor) |
| 6.Straightness Test (optional) |
| 7.Roughness Test (optional) |
| 8.Intergranular Corrosion Test(optional) |
| 9.Impact Test (optional) |
| 10.Grain Size Determinations (optional) |
| NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION. |
The duplex stainless steels have a microstructure, when heat treated properly, of nearly equal proportions of austenite and ferrite. This microstructure ensures that the duplexes are much more resistant to stress corrosion cracking (SCC) than austenitic stainless steels. The specification 0.2% Proof Stress of the duplexes is more than double that of austenitic stainless steels such as the 304 types andu316L types. This often allows down gauging in the design, depending on Young's Modulus and buckling limitations.
The microstructures inside duplex stainless steels are approximately 50 per cent austenite and 50 per cent ferrite, and consequently duplex products share the physical properties of both ferritic and austenitic grades. Duplex stainless steels are resistant to the cracking caused by chloride stress corrosion in austenitic grades, and have improved resistance to localised corrosion. This family of stainless steels has roughly twice the yield strength of their counterpart austenitic grades which means we can use it to design thinner gauge tubing. Higher hardness values provide better wear resistance for high precision tubes.
Duplex steels are easily welded and formed, similar to austenitic grades. Depending on chromium, nickel and molybdenum content, duplex stainless steels are divided into four main categories: lean duplex, duplex, super duplex and hyper duplex. This family of alloys has great advantages in both material and engineered fabrication costs.
Typical applications for this alloy group include heat exchanger tubes, umbilicals, structural tanks, pulp and paper making equipment, pipes and fittings, and seawater handling systems.
