ASME SA204 Gr. B Steel Plate for Pressure Vessels
Guangzhou Kingmetal Steel Industry Co., Ltd.- Type：Steel Plate
- Standard：ASTM, AISI, GB, DIN
- Certification：ISO
- Surface Treatment：Coated
- Technique：Hot Rolled
- Application：Boiler Plate
Base Info
- Model NO.：KM-143
- Special Use：High-strength Steel Plate, Wear Resistant Steel
- Stock：Stock
- Width：10mm~3500mm
- Length：2m, 3m, 6m, 8m, 12m, or as Required.
- Surface：Varnished, PE Coated, Galvanized.
- MOQ：1000kgs
- Price Term：Ex-Work, Fob, CIF, CFR, etc.
- Delivery Time：Prompt Delivery, or as Order′s Quantity.
- Transport Package：Standard Export Seaworthy
- Specification：Thickness: 0.3mm~500mm
- Trademark：KINGMETAL
- Origin：China
- Production Capacity：300 Ton,Month
Description
Composition
Type
Thickness(mm)
B
C ≤
Heat analyse
Product analyse
≤25
0.20
>25~50
0.23
>50~100
0.25
>100
0.27
Mn ≤
Heat analyse
-
0.90
Product analyse
-
0.98
P ≤ , S ≤
Heat analyse
-
0.035
Product analyse
-
0.035
Si
Heat analyse
-
0.15~0.40
Product analyse
-
0.13~0.45
Mo
Heat analyse
-
0.45~0.60
Product analyse
-
0.41~0.64
ASME SA204 Gr.B steel Mechanical Properties:
Grade
Tensile Strength kis
[MPa]
Yield Strength min, kis
[MPa]
Elongation in 8 in. [200 mm],
min, %
Elongation in 2 in. [50 mm],
min, %
SA204 Gr B
70-90 [485-620]
40 [275]
17
21
ASME SA204 Gr.B Supplementary Technology:
HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1 S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17
ASME SA204 Gr.B steel chief application:
ASME SA204 Gr.B pressure vessel steel is widely used in petroleum, chemical industry, power station, boiler, etc, used to make the reactor, heat exchanger, separator, spherical tank, liquefied gas, nuclear reactor pressure vessel, boiler steam drum steam, liquefied petroleum, hydropower station, high pressure pipe.
