New Technology Hot-Dipped Galvanized Steel Wire 1.0-5.0mm
ZHEJIANG WANSHENG YUNHE STEEL CABLE CO., LTD.- Certification：ISO, CCC, CE
- Surface：Smooth
- Technique：Galvanized
- Application：Rope, Packaging, Netting, Manufacturing, Fencing, Construction, Steel Cable
- Alloy or Not：Non-alloy
- Standard：BS, JIS, GB, ASTM, DIN, AISI
Base Info
- Samples：Free Samples
- MOQ：1 Ton
- Transport Package：Coil Packing, Z2 Packing, Wooden Reel Packing
- Specification：0.8-5.0
- Trademark：yunhe
- Origin：China
- HS Code：7217200000
- Production Capacity：12000 Per Month
Description
Zinc-coated steel wire for stranded conductors(Strength General) diameter mm Tensile Strebgth
No Less Than Tensile Strength
No Less Than LD=250mm Elongation
Noless Than% Number Of Twist/360
No less Than Diameter Of Core ROD
FOR Wrap Test(times) (A)General strength >1.24-2.25 1340 1170 3 18 1D >2.25-2.75 1310 1140 3 16 1D >2.75-3.0 1310 1140 3.5 16 1D >3.0-3.5 1290 1100 3.5 14 1D >3.5-4.25 1290 1100 4 12 1D >4.25-4.75 1290 1100 4 12 1D >4.75-5.5 1290 1100 4 12 1D (A)Higher strength >1.24-2.25 1450 1310 2.5 16 3D >2.25-2.75 1410 1280 2.5 16 3D >2.75-3.0 1410 1280 3 16 4D >3.0-3.5 1410 1240 3 14 4D >3.5-4.25 1380 1170 3 12 4D >4.25-4.75 1380 1170 3 12 4D Extra Higher Strength >1.24-2.25 1620 1450 2 14 3D >2.25-2.75 1590 1410 2 14 3D >2.75-3.0 1590 1410 2.5 12 4D >3.0-3.5 1550 1380 2.5 12 4D >3.5-4.25 1520 1340 2.5 10 4D >4.25-4.75 1520 1340 2.5 10 4D
No Less Than
No Less Than
Noless Than%
No less Than
FOR Wrap Test(times)
| Zinc coating | EN10257 |
| Material | Q195/Q235/SAE1006/SAE1008 45# 60# 65# 70# 80# 72A 72B 82B |
| Key word | Hard Drawn Steel Wire |
| Diameter | 0.3mm -13mm |
| Surface treatment | hot-dipped/electric /ungalvanized /phosphate galvanized |
| Price Term | FOB, CFR, CIF,LC |
| Package | Standard export packing. In coils, water-proof cloth. Or according to customer's needs. |
| Tensile strength | 200-2100Mpa TO Galvanzied Steel Hard Drawn Steel Wire |
| Surface | hot-dipped/electric /ungalvanized /phosphate galvanized TO Low Caron Hard Drawn Steel Wire |
| Port of loading | zhejiang,China |
| Usage | Cable , agriculture ,ACSR , gabion , |
