• Model NO.：13CrMo4-5 seamless steel tube
• out Diameter：20-508mm
• Thickness：2-60mm
• Length：11-12m
• Transport Package：in Bundles
• Specification：89*8*10000mm
• Trademark：Zayi
• Origin：Shandong
• HS Code：7304599090
• Production Capacity：5000tons,Month

CSiMnPSCrMoNCu0.08 - 0.18max   0.350.4 - 1max   0.025max   0.010.7 - 1.150.4 - 0.6max   0.012max   0.3Mechanical properties of   steel   13CrMo4-5 (1.7335)Nominal thickness (mm):  to 6060 - 100100 - 150150 - 250Rm - Tensile strength (MPa)450-600440-590430-580420-570Nominal thickness (mm):  to 1616 - 6060 - 100100 - 150150 - 250ReH - Minimum yield strength (MPa)290-300290270255245KV - Impact energy (J) transverse,+20°
27KV - Impact energy (J) longitud.,+20°
40-44A - Min. elongation at fracture (%)19-22Equivalent grades of   steel   13CrMo4-5 (1.7335)13CrMo4-5A387Gr.1213CrMo4-4SFVAF1215CD2.0562014CrMo314CrMo4.512CrMo221615HM1512113CrMo44KW12KHMF32Gr.P12  15CD4-05620-44014CrMo4-5      15KHMP32   15CD4-5620Gr.2714CrMo4.5
Standard:API 5L, ASME, ASTM,  DIN, GB8162, GB8163, GB5310,etc.
Material:ASTM A106 GRB/ A53 GRB/ API 5L X42,X52,X60,X65,X70GRB/
API 5 CT/ ST42/ST37/ ST52.Q235/Q345/A179etc.
Out diameter:1/8"-20",10mm-720mm
Wall thickness:SCH5~SCH140,STD,XS,XXS,2mm~80mm
Length:1-12m or as customers required
Surface:Black painting, black varnish, transparent oil, epoxy coating, etc.
Technical:Hot rolled,cold extrustion,welded
Usage:
 1.  Low and middle pressure fluid transportation pipeline
 2.  Casing Tube
 3.  Boiler Pipe
 4.   Petroleum and natural gas industry
 5.  Chemistry industry
 6.  Electric industry
Packing:export standard packing,such as in bundles
Delivery time:5 days after receive the deposit
