High Carbon Wire Rod Galvanized Steel Wire Strand for Vibration Damper
Nanjing Suntay Steel Co., Ltd.- Certification：ISO, CCC
- Surface：Smooth
- Technique：Galvanized
- Application：Rope, Packaging, Netting, Manufacturing, Fencing, Construction
- Alloy or Not：Non-alloy
- Standard：BS, JIS, GB, ASTM, DIN, AISI
Base Info
- Model NO.：GS-21-3
- Transport Package：Standard Export Packing
- Specification：1.0-4.8mm
- Trademark：Suntay
- Origin：Jiangsu, China
- HS Code：731210
- Production Capacity：50000tons,Year
Description
Wire Diamater(mm)
Diamater Tolerance(mm)
Weight of Zinc-coating(g/m2)
Stress at 1% Extension,Min(Mpa)
Tensile Strength
Min.(Mpa)
Elongation in 250mm,Min(%)
1.57-1.90
+0.04,-0.03
210
1310
1450
3.0
Over 1.9-2.3
+0.04,-0.03
220
1310
1450
3.0
Over 2.3-2.7
+0.05,-0.05
230
1280
1410
3.5
Over 2.7-3.1
+0.05,-0.05
240
1280
1410
3.5
Over3.1-3.5
+0.08,-0.05
260
1240
1410
4.0
Over 3.5-3.9
+0.08,-0.05
270
1240
1410
4.0
Over 3.9-4.5
+0.1,-0.08
275
1170
1380
4.0
Over 4.5-4.8
+0.1,-0.08
300
1170
1380
4.0
Galvanized Steel Wire Strand for ACSR Conductor as per ASTM A 475
Norminal Diamater of Strand
No. of Wires
Diamater of Wire
Tolerance of Wire
Weight
Zinc-coating
Breaking Loading
mm
-
mm
mm
Kg/Km
g/m2
KN
3.18
7
1.04
±0.05
48
122
8.14
3.97
7
1.32
±0.05
76
122
13.078
4.76
7
1.57
±0.08
109
153
17.748
5.56
7
1.83
±0.08
146
153
24.02
6.35
7
2.03
±0.08
180
183
29.581
7.14
7
2.36
±0.10
244
214
39.812
7.94
7
2.64
±0.10
305
244
49.82
9.52
7
3.05
±0.10
407
259
68.503
11.11
7
3.68
±0.13
595
275
92.523
12.7
7
4.19
±0.13
770
275
119.657
